Lumileds
- Companies developing automotive, mobile, IoT and illumination lighting applications need a partner who can collaborate with them to push the boundaries of light. With over 100 years of inventions and industry firsts, Lumileds is a global lighting solutions company that helps customers around the world deliver differentiated solutions to gain and maintain a competitive edge. As the inventor of Xenon technology, a pioneer in halogen lighting and the leader in high performance LEDs, Lumileds builds innovation, quality and reliability into its technology, products and every customer engagement. Together with its customers, Lumileds is making the world safer, better and more beautiful—with light.
Part Number
Manufacturer
Description
Unit Price
In Stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 2700K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1224 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 113 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 85
Viewing Angle : -
Features : -
Size / Dimension : 600.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
43 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1512 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 140 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 300.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1512 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 140 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 600.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
703 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1512 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 140 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 600.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
156 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 2352 lm (Typ)
Current - Test : 800mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 21V
Lumens/Watt @ Current - Test : 140 lm/W
Current - Max : 1.6A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 525.40mm L x 5.25mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
499 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 4536 lm (Typ)
Current - Test : 900mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 36V
Lumens/Watt @ Current - Test : 140 lm/W
Current - Max : 1.8A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 1150.00mm L x 5.25mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
157 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 3500K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1548 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 143 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 300.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
7 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 3500K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1548 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 143 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 300.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
1 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 3500K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1548 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 143 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 600.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
642 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1584 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 147 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 300.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
785 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1584 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 147 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 300.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
212 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1584 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 147 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 600.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
279 in stock
