Lumileds
- Companies developing automotive, mobile, IoT and illumination lighting applications need a partner who can collaborate with them to push the boundaries of light. With over 100 years of inventions and industry firsts, Lumileds is a global lighting solutions company that helps customers around the world deliver differentiated solutions to gain and maintain a competitive edge. As the inventor of Xenon technology, a pioneer in halogen lighting and the leader in high performance LEDs, Lumileds builds innovation, quality and reliability into its technology, products and every customer engagement. Together with its customers, Lumileds is making the world safer, better and more beautiful—with light.
Part Number
Manufacturer
Description
Unit Price
In Stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON XR-3020
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 3500K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1070 lm (Typ)
Current - Test : 200mA
Temperature - Test : 45°C
Voltage - Forward (Vf) (Typ) : 34.8V
Lumens/Watt @ Current - Test : 154 lm/W
Current - Max : 480mA
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 279.20mm L x 20.00mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
896 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON XR-3020
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 3500K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 2140 lm (Typ)
Current - Test : 400mA
Temperature - Test : 45°C
Voltage - Forward (Vf) (Typ) : 34.8V
Lumens/Watt @ Current - Test : 154 lm/W
Current - Max : 600mA
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 558.40mm L x 20.00mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
494 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON XR-3020
Part Status : Active
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1088 lm (Typ)
Current - Test : 200mA
Temperature - Test : 45°C
Voltage - Forward (Vf) (Typ) : 34.8V
Lumens/Watt @ Current - Test : 156 lm/W
Current - Max : 480mA
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 279.20mm L x 20.00mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
154 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON XR-3020
Part Status : Active
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 2176 lm (Typ)
Current - Test : 400mA
Temperature - Test : 45°C
Voltage - Forward (Vf) (Typ) : 34.8V
Lumens/Watt @ Current - Test : 156 lm/W
Current - Max : 600mA
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 558.40mm L x 20.00mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
925 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON XR-3020
Part Status : Active
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 890 lm (Typ)
Current - Test : 200mA
Temperature - Test : 45°C
Voltage - Forward (Vf) (Typ) : 34.8V
Lumens/Watt @ Current - Test : 128 lm/W
Current - Max : 480mA
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : With Connector
Size / Dimension : 279.20mm L x 20.00mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
963 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON XR-3020
Part Status : Active
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1780 lm (Typ)
Current - Test : 400mA
Temperature - Test : 45°C
Voltage - Forward (Vf) (Typ) : 34.8V
Lumens/Watt @ Current - Test : 128 lm/W
Current - Max : 600mA
CRI (Color Rendering Index) : 90
Viewing Angle : -
Features : With Connector
Size / Dimension : 558.40mm L x 20.00mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
91 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON XR-3020
Part Status : Active
Type : LED Module
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1088 lm (Typ)
Current - Test : 200mA
Temperature - Test : 45°C
Voltage - Forward (Vf) (Typ) : 34.8V
Lumens/Watt @ Current - Test : 156 lm/W
Current - Max : 480mA
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 279.20mm L x 20.00mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
774 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON XR-3020
Part Status : Active
Type : LED Module
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 2176 lm (Typ)
Current - Test : 400mA
Temperature - Test : 45°C
Voltage - Forward (Vf) (Typ) : 34.8V
Lumens/Watt @ Current - Test : 156 lm/W
Current - Max : 600mA
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 558.40mm L x 20.00mm W
Height : 3.00mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
412 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Cut Tape (CT)
Alternate Packaging
Series : LUXEON XF-3014 CV
Part Status : Discontinued at
Type : LED Engine
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 102 lm (Typ)
Current - Test : 45mA
Temperature - Test : 50°C
Voltage - Forward (Vf) (Typ) : 24V
Lumens/Watt @ Current - Test : 94 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 96.00mm L x 10.00mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Flat
0
1 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tape & Reel (TR)
Series : LUXEON XF-3014 CV
Part Status : Discontinued at
Type : LED Engine
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 112 lm (Typ)
Current - Test : 45mA
Temperature - Test : 50°C
Voltage - Forward (Vf) (Typ) : 24V
Lumens/Watt @ Current - Test : 104 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 96.00mm L x 10.00mm W
Height : -
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 2200K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 1206 lm (Typ)
Current - Test : 600mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 18V
Lumens/Watt @ Current - Test : 112 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 300.00mm L x 10.00mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
78 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Strip
Series : LUXEON XF-3535L
Part Status : Active
Type : LED Module
Color : White, Warm
CCT (K) : 2700K
Wavelength : -
Configuration : Linear Light Strip, Flexible
Flux @ Current/Temperature - Test : 2296 lm (Typ)
Current - Test : 800mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 21V
Lumens/Watt @ Current - Test : 137 lm/W
Current - Max : 1.2A
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : -
Size / Dimension : 525.40mm L x 5.25mm W
Height : 1.23mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
12 in stock
