Sumida
- Sumida is one of the leading manufacturers of coils and wire wound electronic products. Sumida currently has over 31000 products in its coil catalog-attesting to the diversity to which coil technology can be applied in the present day information age. All of Sumida's products are manufactured outside of Japan in various locations in the Asian region as well as in Mexico. This has allowed Sumida to keep costs to a minimum, spread risk and increase response times.
Sumida components can be found in audio visual equipment, CD-ROM drives, DVD/MD products, modems, networking hardware, liquid crystal display monitors, computer peripherals, air-conditioners, electronic automotive products such as Anti Lock Braking Systems, and a plethora of other electronic devices. See the product section of our site for more on our extensive range.
Part Number
Manufacturer
Description
Unit Price
In Stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D28
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 15µH
Tolerance : ±30%
Current Rating : 2.35A
Current - Saturation : 1.9A
Shielding : Shielded
DC Resistance (DCR) : 69 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.118" (3.00mm)
0
1771 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D28
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 22µH
Tolerance : ±30%
Current Rating : 1.85A
Current - Saturation : 1.6A
Shielding : Shielded
DC Resistance (DCR) : 99 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.118" (3.00mm)
0
2066 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D28
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 2.5µH
Tolerance : ±30%
Current Rating : 6.4A
Current - Saturation : 4.5A
Shielding : Shielded
DC Resistance (DCR) : 15.6 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.118" (3.00mm)
0
79 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D28
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 3.3µH
Tolerance : ±30%
Current Rating : 6A
Current - Saturation : 4A
Shielding : Shielded
DC Resistance (DCR) : 18.2 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.118" (3.00mm)
0
2486 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D28
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 4.7µH
Tolerance : ±30%
Current Rating : 4.5A
Current - Saturation : 3.4A
Shielding : Shielded
DC Resistance (DCR) : 24.7 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.118" (3.00mm)
0
960 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D38/A
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 10µH
Tolerance : ±20%
Current Rating : 1.72A
Current - Saturation : -
Shielding : Shielded
DC Resistance (DCR) : 42.5 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 125°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
100 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Series : CDRH8D38
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 10µH
Tolerance : ±30%
Current Rating : 3.2A
Current - Saturation : 3A
Shielding : Shielded
DC Resistance (DCR) : 48 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
17151 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D38
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 15µH
Tolerance : ±30%
Current Rating : 2.5A
Current - Saturation : 2.75A
Shielding : Shielded
DC Resistance (DCR) : 67 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
13921 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D38
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 22µH
Tolerance : ±30%
Current Rating : 2A
Current - Saturation : 2.3A
Shielding : Shielded
DC Resistance (DCR) : 105 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
4209 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D38
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 2.5µH
Tolerance : ±30%
Current Rating : 6A
Current - Saturation : 6.5A
Shielding : Shielded
DC Resistance (DCR) : 17.5 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
1095 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D38
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 33µH
Tolerance : ±30%
Current Rating : 1.6A
Current - Saturation : 1.75A
Shielding : Shielded
DC Resistance (DCR) : 157 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
175 in stock
Sumida Corporation
Manufacturer : Sumida America Components Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : CDRH8D38
Part Status : Active
Type : -
Material - Core : Ferrite
Inductance : 47µH
Tolerance : ±30%
Current Rating : 1.42A
Current - Saturation : 1.52A
Shielding : Shielded
DC Resistance (DCR) : 189 mOhm Max
Q @ Freq : -
Frequency - Self Resonant : -
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100kHz
Features : -
Mounting Type : Surface Mount
Package / Case : Nonstandard
Supplier Device Package : -
Size / Dimension : 0.315" L x 0.315" W (8.00mm x 8.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
4142 in stock
