Mallory Sonalert Products
- Headquartered in a new 22,000 square foot facility in Indianapolis, Indiana, Mallory Sonalert Products, Inc. is a leader in the manufacture and development of Sonalert® electronic audible signal products. The company has made its trademarked Sonalert line for over thirty years. In addition to sonalert products, Mallory also distributes a full range of audible signal devices including transducers, indicators, sirens, buzzers and related hardware to a broad range of customers in industrial, military and consumer electronic markets.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.85kHz
Technology : Piezo
Operating Mode : Ding Dong
Duration : -
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : -
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Double Pulse, Fast
Duration : 2 PPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
3 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Double Pulse, Fast
Duration : 2 PPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : -
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Double Pulse, Slow
Duration : 0.5 PPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
1 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Double Pulse, Slow
Duration : 0.5 PPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : -
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.85kHz
Technology : Piezo
Operating Mode : Warble, Fast
Duration : 7 WPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
1 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.85kHz
Technology : Piezo
Operating Mode : Warble, Fast
Duration : 7 WPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : -
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.85kHz
Technology : Piezo
Operating Mode : Warble, Slow
Duration : 1.5 WPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
2 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.85kHz
Technology : Piezo
Operating Mode : Warble, Slow
Duration : 1.5 WPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Pulse, Short
Duration : 1 PPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Pulse, Short
Duration : 1 PPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 4kHz
Technology : Piezo
Operating Mode : Siren, Fast
Duration : 3.5 SPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
