Mallory Sonalert Products
- Headquartered in a new 22,000 square foot facility in Indianapolis, Indiana, Mallory Sonalert Products, Inc. is a leader in the manufacture and development of Sonalert® electronic audible signal products. The company has made its trademarked Sonalert line for over thirty years. In addition to sonalert products, Mallory also distributes a full range of audible signal devices including transducers, indicators, sirens, buzzers and related hardware to a broad range of customers in industrial, military and consumer electronic markets.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 4kHz
Technology : Piezo
Operating Mode : Siren, Slow
Duration : 3.5 SPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : -
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 4kHz
Technology : Piezo
Operating Mode : Siren, Fast
Duration : 7 SPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
1 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 4kHz
Technology : Piezo
Operating Mode : Siren, Fast
Duration : 7 SPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : -
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Speed Up, Fast
Duration : -
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
5 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Speed Up, Fast
Duration : 0.5 ~ 8 PPS in 30 Sec
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : -
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.35kHz
Technology : Piezo
Operating Mode : Ringer, 3 Tone
Duration : -
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
85 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.35kHz
Technology : Piezo
Operating Mode : Ringer, 3 Tone
Duration : -
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.95kHz
Technology : Piezo
Operating Mode : Whooping
Duration : 5 SPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.95kHz
Technology : Piezo
Operating Mode : Whooping
Duration : 5 SPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.95kHz
Technology : Piezo
Operating Mode : Whooping
Duration : 1 SPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.95kHz
Technology : Piezo
Operating Mode : Whooping
Duration : 1 SPS
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.85kHz
Technology : Piezo
Operating Mode : Chirp
Duration : Repeating every 1.2 Sec
Sound Pressure Level (SPL) : 75dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
