Mallory Sonalert Products
- Headquartered in a new 22,000 square foot facility in Indianapolis, Indiana, Mallory Sonalert Products, Inc. is a leader in the manufacture and development of Sonalert® electronic audible signal products. The company has made its trademarked Sonalert line for over thirty years. In addition to sonalert products, Mallory also distributes a full range of audible signal devices including transducers, indicators, sirens, buzzers and related hardware to a broad range of customers in industrial, military and consumer electronic markets.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : LSC
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC, DC
Voltage - Rated : -
Voltage Range : 60 ~ 250V
Frequency : 2.9kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : -
Sound Pressure Level (SPL) : 82dB @ 60V, 61cm
Current - Supply : 42 ~ 61mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : Screw Terminal, Quick Connect Tab - 0.250" (6.35mm)
Size / Dimension : 1.687" Dia (42.85mm)
Height - Seated (Max) : 1.809" (45.96mm)
0
25 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : LSC
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC, DC
Voltage - Rated : -
Voltage Range : 60 ~ 250V
Frequency : 2.9kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : 2 PPS
Sound Pressure Level (SPL) : 82dB @ 60V, 61cm
Current - Supply : 42 ~ 61mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : Screw Terminals
Size / Dimension : 1.687" Dia (42.85mm)
Height - Seated (Max) : 1.507" (38.28mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : LSC
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 6 ~ 16V
Frequency : 2.9kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : -
Sound Pressure Level (SPL) : 80dB @ 6V, 61cm
Current - Supply : 40 ~ 60mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : Screw Terminal, Quick Connect Tab - 0.250" (6.35mm)
Size / Dimension : 1.687" Dia (42.85mm)
Height - Seated (Max) : 1.507" (38.28mm)
0
11 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : LSC
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 6 ~ 16V
Frequency : 2.9kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : 2 PPS
Sound Pressure Level (SPL) : 80dB @ 6V, 61cm
Current - Supply : 65mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : Screw Terminals
Size / Dimension : 1.687" Dia (42.85mm)
Height - Seated (Max) : 1.507" (38.28mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : LSC
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC, DC
Voltage - Rated : -
Voltage Range : 9 ~ 28V
Frequency : 2.9kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : -
Sound Pressure Level (SPL) : 80dB @ 9V, 10cm
Current - Supply : 65mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : Screw Terminal, Quick Connect Tab - 0.250" (6.35mm)
Size / Dimension : 1.687" Dia (42.85mm)
Height - Seated (Max) : 1.431" (36.34mm)
0
83 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : LSC
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC, DC
Voltage - Rated : -
Voltage Range : 9 ~ 28V
Frequency : 2.9kHz
Technology : Piezo
Operating Mode : Single Tone, Visual Indicator
Duration : 2 PPS
Sound Pressure Level (SPL) : 80dB @ 9V, 61cm
Current - Supply : 65mA
Port Location : Top
Operating Temperature : -30°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount
Termination : Screw Terminals
Size / Dimension : 1.687" Dia (42.85mm)
Height - Seated (Max) : 1.507" (38.28mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MAS
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : AC
Voltage - Rated : 120V
Voltage Range : 60 ~ 130V
Frequency : Multiple
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 90dB @ 120V, 30cm
Current - Supply : 20mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange, Right Angle
Termination : Screw Terminal, Quick Connect Tab - 0.248" (6.30mm)
Size / Dimension : 1.752" L x 1.220" W (44.50mm x 31.00mm)
Height - Seated (Max) : 1.008" (25.60mm)
0
583 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Strip
Series : MAS
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 8 ~ 16V
Frequency : 2.7kHz
Technology : Piezo
Operating Mode : Pulse, Fast
Duration : -
Sound Pressure Level (SPL) : 87dB @ 12V, 10cm
Current - Supply : 20mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Panel Mount, Flange, Right Angle
Termination : Screw Terminal, Quick Connect Tab - 0.248" (6.30mm)
Size / Dimension : 2.437" L x 1.220" W (61.90mm x 31.00mm)
Height - Seated (Max) : 1.008" (25.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MAS
Part Status : Obsolete
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 9 ~ 12V
Frequency : 2.7kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 103dB @ 12V, 10cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -20°C ~ 90°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.024" Dia (26.00mm)
Height - Seated (Max) : 0.862" (21.90mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MAS
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 9 ~ 12V
Frequency : 2.7kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 103dB @ 12V, 10cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -20°C ~ 90°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.024" Dia (26.00mm)
Height - Seated (Max) : 0.862" (21.90mm)
0
545 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MAS
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 9 ~ 12V
Frequency : 2.7kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 103dB @ 12V, 10cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -20°C ~ 90°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.024" Dia (26.00mm)
Height - Seated (Max) : 0.862" (21.90mm)
0
36 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MAS
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 6V
Voltage Range : 1.5 ~ 6V
Frequency : 2.8kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 105dB @ 6V, 10cm
Current - Supply : 130mA
Port Location : Top
Operating Temperature : -20°C ~ 90°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.024" Dia (26.00mm)
Height - Seated (Max) : 0.862" (21.90mm)
0
688 in stock
