Mallory Sonalert Products
- Headquartered in a new 22,000 square foot facility in Indianapolis, Indiana, Mallory Sonalert Products, Inc. is a leader in the manufacture and development of Sonalert® electronic audible signal products. The company has made its trademarked Sonalert line for over thirty years. In addition to sonalert products, Mallory also distributes a full range of audible signal devices including transducers, indicators, sirens, buzzers and related hardware to a broad range of customers in industrial, military and consumer electronic markets.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MAS
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 1.5 ~ 6V
Frequency : 2.8kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 105dB @ 6V, 10cm
Current - Supply : 130mA
Port Location : Top
Operating Temperature : -20°C ~ 90°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.024" Dia (26.00mm)
Height - Seated (Max) : 0.862" (21.90mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MAS
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 6 ~ 14V
Frequency : 2.8kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 103dB @ 12V, 10cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -20°C ~ 90°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.024" Dia (26.00mm)
Height - Seated (Max) : 0.862" (21.90mm)
0
5924 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MAS
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 6 ~ 14V
Frequency : 2.8kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 103dB @ 12V, 10cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -20°C ~ 90°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 1.024" Dia (26.00mm)
Height - Seated (Max) : 0.862" (21.90mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MCP
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 20V
Frequency : 2.5kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 95dB @ 12V, 30cm
Current - Supply : 20mA
Port Location : Top
Operating Temperature : -20°C ~ 90°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.921" Dia (23.40mm)
Height - Seated (Max) : 0.717" (18.20mm)
0
1274 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MCP
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : 12V
Voltage Range : 3 ~ 20V
Frequency : 3.15kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 55dB @ 3V, 61cm
Current - Supply : 3 ~ 25mA
Port Location : Top
Operating Temperature : -20°C ~ 90°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.945" Dia (24.00mm)
Height - Seated (Max) : 0.689" (17.50mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : -
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.85kHz
Technology : Piezo
Operating Mode : Chirp
Duration : Repeating every 1.2 Sec
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
5 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.85kHz
Technology : Piezo
Operating Mode : Chirp
Duration : Repeating every 1.2 Sec
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Chime
Duration : Repeating every 3 Sec
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Chime
Duration : Repeating every 3 Sec
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : -
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Chime
Duration : Repeating every 1 Sec
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
46 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : MSE
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.9kHz
Technology : Piezo
Operating Mode : Chime
Duration : Repeating every 1 Sec
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : Washable
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
100 in stock
Mallory Sonalert Products
Manufacturer : Mallory Sonalert Products Inc.
Packaging : Bulk
Series : -
Part Status : Active
Driver Circuitry : Indicator, Internally Driven
Input Type : DC
Voltage - Rated : -
Voltage Range : 7 ~ 14V
Frequency : 3.85kHz
Technology : Piezo
Operating Mode : Ding Dong
Duration : -
Sound Pressure Level (SPL) : 85dB @ 7V, 30cm
Current - Supply : 50mA
Port Location : Top
Operating Temperature : -40°C ~ 65°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Through Hole
Termination : PC Pins
Size / Dimension : 0.906" L x 0.906" W (23.00mm x 23.00mm)
Height - Seated (Max) : 0.535" (13.60mm)
0
3 in stock
