Mechatronics
- Mechatronics is a manufacturer of brushless cooling fans and thermal solutions headquartered near Seattle, WA. Mechatronics product offering includes AC axial fans, DC axial fans, AC blowers, DC blowers, AC motorized impellers and value-added assemblies. In addition to our standard products, we offer tailored solutions to fit customer specific requirements from minor modifications to fully custom products.
With factories located in Indonesia, Taiwan and China, Mechatronics offers technologically advanced products, superior quality, competitive pricing and exceptional service.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 48VDC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 125.0 CFM (3.50m鲁/min)
Static Pressure : 0.320 in H2O (79.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 43.0 dB(A)
Power (Watts) : -
RPM : 2800 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
6 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 88.0 CFM (2.46m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 34.0 dB(A)
Power (Watts) : -
RPM : 2000 RPM
Termination : 3 Wire Leads
Ingress Protection : IP57 - Dust Protected, Waterproof
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1338
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 127mm L x 127mm H
Width : 38.00mm
Air Flow : 141.0 CFM (3.95m鲁/min)
Static Pressure : 0.590 in H2O (147.0 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Sensor
Noise : 49.0 dB(A)
Power (Watts) : -
RPM : 3200 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.784 lb (355.62g)
0
9 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1338
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 127mm L x 127mm H
Width : 38.00mm
Air Flow : 122.1 CFM (3.42m鲁/min)
Static Pressure : 0.460 in H2O (114.6 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 46.0 dB(A)
Power (Watts) : -
RPM : 2800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.784 lb (355.62g)
0
361 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G4010
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.30mm
Air Flow : 11.0 CFM (0.308m鲁/min)
Static Pressure : 0.390 in H2O (97.1 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 41.0 dB(A)
Power (Watts) : -
RPM : 10000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.026 lb (11.79g)
0
20 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G4010
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.30mm
Air Flow : 11.0 CFM (0.308m鲁/min)
Static Pressure : 0.390 in H2O (97.1 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 41.0 dB(A)
Power (Watts) : -
RPM : 10000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.026 lb (11.79g)
0
327 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G4010
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.30mm
Air Flow : 11.0 CFM (0.308m鲁/min)
Static Pressure : 0.390 in H2O (97.1 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 41.0 dB(A)
Power (Watts) : -
RPM : 10000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.026 lb (11.79g)
0
6 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G4010
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.30mm
Air Flow : 9.0 CFM (0.252m鲁/min)
Static Pressure : 0.250 in H2O (62.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 35.0 dB(A)
Power (Watts) : -
RPM : 8000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.026 lb (11.79g)
0
15 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G4010
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.30mm
Air Flow : 9.0 CFM (0.252m鲁/min)
Static Pressure : 0.250 in H2O (62.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 35.0 dB(A)
Power (Watts) : -
RPM : 8000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.026 lb (11.79g)
0
9 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G4010
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.30mm
Air Flow : 9.0 CFM (0.252m鲁/min)
Static Pressure : 0.250 in H2O (62.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 35.0 dB(A)
Power (Watts) : -
RPM : 8000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.026 lb (11.79g)
0
1919 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G4010
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.30mm
Air Flow : 6.0 CFM (0.168m鲁/min)
Static Pressure : 0.110 in H2O (27.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 22.0 dB(A)
Power (Watts) : -
RPM : 5000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.026 lb (11.79g)
0
7 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G4010
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.30mm
Air Flow : 6.0 CFM (0.168m鲁/min)
Static Pressure : 0.110 in H2O (27.4 Pa)
Bearing Type : Sleeve
Fan Type : Tubeaxial
Features : -
Noise : 22.0 dB(A)
Power (Watts) : -
RPM : 5000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.026 lb (11.79g)
0
11 in stock
