Mechatronics
- Mechatronics is a manufacturer of brushless cooling fans and thermal solutions headquartered near Seattle, WA. Mechatronics product offering includes AC axial fans, DC axial fans, AC blowers, DC blowers, AC motorized impellers and value-added assemblies. In addition to our standard products, we offer tailored solutions to fit customer specific requirements from minor modifications to fully custom products.
With factories located in Indonesia, Taiwan and China, Mechatronics offers technologically advanced products, superior quality, competitive pricing and exceptional service.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 48VDC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 158.0 CFM (4.42m鲁/min)
Static Pressure : 0.490 in H2O (122.1 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Sensor
Noise : 49.0 dB(A)
Power (Watts) : -
RPM : 3600 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
2 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 119mm L x 119mm H
Width : 38.00mm
Air Flow : 141.2 CFM (3.95m鲁/min)
Static Pressure : 0.410 in H2O (102.1 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 46.0 dB(A)
Power (Watts) : -
RPM : 3200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
454 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 119mm L x 119mm H
Width : 38.00mm
Air Flow : 141.2 CFM (3.95m鲁/min)
Static Pressure : 0.410 in H2O (102.1 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 46.0 dB(A)
Power (Watts) : -
RPM : 3200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
212 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 48VDC
Size / Dimension : Square - 119mm L x 119mm H
Width : 38.00mm
Air Flow : 141.2 CFM (3.95m鲁/min)
Static Pressure : 0.410 in H2O (102.1 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 46.0 dB(A)
Power (Watts) : -
RPM : 3200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
138 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : *
Part Status : Active
Voltage - Rated : -
Size / Dimension : -
Width : -
Air Flow : -
Static Pressure : -
Bearing Type : -
Fan Type : -
Features : -
Noise : -
Power (Watts) : -
RPM : -
Termination : -
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
805 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 119mm L x 119mm H
Width : 38.00mm
Air Flow : 107.0 CFM (3.00m鲁/min)
Static Pressure : 0.240 in H2O (59.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 38.0 dB(A)
Power (Watts) : -
RPM : 2400 RPM
Termination : 3 Wire Leads
Ingress Protection : IP57 - Dust Protected, Waterproof
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
543 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 119mm L x 119mm H
Width : 38.00mm
Air Flow : 107.0 CFM (3.00m鲁/min)
Static Pressure : 0.240 in H2O (59.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 38.0 dB(A)
Power (Watts) : -
RPM : 2400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
69 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 107.0 CFM (3.00m鲁/min)
Static Pressure : 0.240 in H2O (59.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 38.0 dB(A)
Power (Watts) : -
RPM : 2400 RPM
Termination : 3 Wire Leads
Ingress Protection : IP57 - Dust Protected, Waterproof
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
20 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 119mm L x 119mm H
Width : 38.00mm
Air Flow : 125.0 CFM (3.50m鲁/min)
Static Pressure : 0.320 in H2O (79.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 43.0 dB(A)
Power (Watts) : -
RPM : 2800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
226 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 125.0 CFM (3.50m鲁/min)
Static Pressure : 0.320 in H2O (79.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach), Thermal Overload Protector (TOP)
Noise : 43.0 dB(A)
Power (Watts) : -
RPM : 2800 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
25 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 119mm L x 119mm H
Width : 38.00mm
Air Flow : 125.0 CFM (3.50m鲁/min)
Static Pressure : 0.320 in H2O (79.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 43.0 dB(A)
Power (Watts) : -
RPM : 2800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
35 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G1238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 120mm L x 120mm H
Width : 38.00mm
Air Flow : 125.0 CFM (3.50m鲁/min)
Static Pressure : 0.320 in H2O (79.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 43.0 dB(A)
Power (Watts) : -
RPM : 2800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.74 lb (335.66g)
0
23 in stock
