Johanson Technology
- Johanson Technology was formed to specifically focus on RF, microwave and optical markets. With a highly experienced design team, we produce superior high frequency ceramic solutions through optimization of ceramics, inks and RF circuit designs. Our focus on high frequency has enabled JTI to provide products with exceptional high frequency performance. We have received certification to the ISO9001-2000 standard.
Johanson Technology provides high frequency ceramic solutions for Cellular, WLAN, Bluetooth, WiMax, WiFi, UWB, RF/Microwave, Millimeter Wave, and Fiber Optic applications, as well as custom high frequency ceramic solutions. We offer a broad range of standard products including: Multilayer Capacitors, Single Layer Capacitors, RF Inductors, RF Wire-wound Inductors, Chip Antennas, Baluns, Balanced Filters, Band Pass Filters, High Pass Filter, Low Pass Filters, Couplers, and Diplexers.
Part Number
Manufacturer
Description
Unit Price
In Stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 15nH
Tolerance : ±5%
Current Rating : 250mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 600 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 3.1GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
345225 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 18nH
Tolerance : ±5%
Current Rating : 200mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 650 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 2.9GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
276519 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 1nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 120 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 15GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
46497 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 1.2nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 120 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 15GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
112222 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 1.5nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 130 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 15GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
162841 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 1.8nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 140 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 14GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
59019 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 22nH
Tolerance : ±5%
Current Rating : 200mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 800 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 2.1GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
138780 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 27nH
Tolerance : ±5%
Current Rating : 200mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 900 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 1.9GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
223613 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 2.2nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 160 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 12GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
727189 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 2.4nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 160 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 10GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
34305 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 2.7nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 170 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 9.5GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
267196 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 33nH
Tolerance : ±5%
Current Rating : 200mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 1 Ohm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 1.6GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
1486 in stock
