Johanson Technology
- Johanson Technology was formed to specifically focus on RF, microwave and optical markets. With a highly experienced design team, we produce superior high frequency ceramic solutions through optimization of ceramics, inks and RF circuit designs. Our focus on high frequency has enabled JTI to provide products with exceptional high frequency performance. We have received certification to the ISO9001-2000 standard.
Johanson Technology provides high frequency ceramic solutions for Cellular, WLAN, Bluetooth, WiMax, WiFi, UWB, RF/Microwave, Millimeter Wave, and Fiber Optic applications, as well as custom high frequency ceramic solutions. We offer a broad range of standard products including: Multilayer Capacitors, Single Layer Capacitors, RF Inductors, RF Wire-wound Inductors, Chip Antennas, Baluns, Balanced Filters, Band Pass Filters, High Pass Filter, Low Pass Filters, Couplers, and Diplexers.
Part Number
Manufacturer
Description
Unit Price
In Stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Tape & Reel (TR)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 2.4nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 300 mOhm Max
Q @ Freq : 4 @ 100MHz
Frequency - Self Resonant : 9GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
100 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 2.7nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 320 mOhm Max
Q @ Freq : 4 @ 100MHz
Frequency - Self Resonant : 8.5GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
133471 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 33nH
Tolerance : ±5%
Current Rating : 200mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 2.3 Ohm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 1.5GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
86099 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 39nH
Tolerance : ±5%
Current Rating : 200mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 2.5 Ohm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 1.4GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
65383 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 3.3nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 380 mOhm Max
Q @ Freq : 4 @ 100MHz
Frequency - Self Resonant : 7.5GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
93579 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 3.9nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 450 mOhm Max
Q @ Freq : 4 @ 100MHz
Frequency - Self Resonant : 6.8GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
14406 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 4.7nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 500 mOhm Max
Q @ Freq : 4 @ 100MHz
Frequency - Self Resonant : 6GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
67608 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 5.6nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 600 mOhm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 5.5GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
32489 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 6.8nH
Tolerance : ±5%
Current Rating : 250mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 700 mOhm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 4.8GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
15642 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 8.2nH
Tolerance : ±5%
Current Rating : 250mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 900 mOhm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 4.6GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
17804 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 10nH
Tolerance : ±5%
Current Rating : 250mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 450 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 3.7GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
41630 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 12nH
Tolerance : ±5%
Current Rating : 250mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 500 mOhm Max
Q @ Freq : 8 @ 100MHz
Frequency - Self Resonant : 3.2GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0402 (1005 Metric)
Supplier Device Package : 0402 (1005 Metric)
Size / Dimension : 0.039" L x 0.020" W (1.00mm x 0.50mm)
Height - Seated (Max) : 0.024" (0.60mm)
0
130187 in stock
