Johanson Technology
- Johanson Technology was formed to specifically focus on RF, microwave and optical markets. With a highly experienced design team, we produce superior high frequency ceramic solutions through optimization of ceramics, inks and RF circuit designs. Our focus on high frequency has enabled JTI to provide products with exceptional high frequency performance. We have received certification to the ISO9001-2000 standard.
Johanson Technology provides high frequency ceramic solutions for Cellular, WLAN, Bluetooth, WiMax, WiFi, UWB, RF/Microwave, Millimeter Wave, and Fiber Optic applications, as well as custom high frequency ceramic solutions. We offer a broad range of standard products including: Multilayer Capacitors, Single Layer Capacitors, RF Inductors, RF Wire-wound Inductors, Chip Antennas, Baluns, Balanced Filters, Band Pass Filters, High Pass Filter, Low Pass Filters, Couplers, and Diplexers.
Part Number
Manufacturer
Description
Unit Price
In Stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 10nH
Tolerance : ±5%
Current Rating : 250mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 1.2 Ohm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 4GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
53731 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 12nH
Tolerance : ±5%
Current Rating : 250mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 1.3 Ohm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 3.5GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
22008 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Tape & Reel (TR)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 13nH
Tolerance : ±5%
Current Rating : 250mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 1.35 Ohm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 3.5GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
100 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 15nH
Tolerance : ±5%
Current Rating : 250mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 1.4 Ohm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 3GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
23073 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 18nH
Tolerance : ±5%
Current Rating : 200mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 1.5 Ohm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 2.5GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
56996 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 1nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 120 mOhm Max
Q @ Freq : 4 @ 100MHz
Frequency - Self Resonant : 13GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
24435 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 1.2nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 150 mOhm Max
Q @ Freq : 4 @ 100MHz
Frequency - Self Resonant : 13GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
20961 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 1.5nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 180 mOhm Max
Q @ Freq : 4 @ 100MHz
Frequency - Self Resonant : 13GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
95587 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 1.8nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 220 mOhm Max
Q @ Freq : 4 @ 100MHz
Frequency - Self Resonant : 10.5GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
3716 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 22nH
Tolerance : ±5%
Current Rating : 200mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 1.8 Ohm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 2.2GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
17682 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 27nH
Tolerance : ±5%
Current Rating : 200mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 2 Ohm Max
Q @ Freq : 5 @ 100MHz
Frequency - Self Resonant : 1.8GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
11681 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Type : Multilayer
Material - Core : Ceramic
Inductance : 2.2nH
Tolerance : ±0.3nH
Current Rating : 300mA
Current - Saturation : -
Shielding : Unshielded
DC Resistance (DCR) : 260 mOhm Max
Q @ Freq : 4 @ 100MHz
Frequency - Self Resonant : 9.5GHz
Ratings : -
Operating Temperature : -40°C ~ 100°C
Inductance Frequency - Test : 100MHz
Features : -
Mounting Type : Surface Mount
Package / Case : 0201 (0603 Metric)
Supplier Device Package : 0201 (0603 Metric)
Size / Dimension : 0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max) : 0.013" (0.33mm)
0
7393 in stock
