Taitien

- Taitien is a leading global manufacturer of frequency control products and offers a wide range of quartz crystals, oscillators, VCXOs, TCXOs, OCXOs, precision crystals, and thickness monitor crystals. The company is ISO 9001 and TS 16949 certified, with design and application engineering resources in Taiwan, China, and The United States.

Taitien was founded in 1976, as one of the original manufacturers of the tuning fork. In the early 1990s, Taitien became a primary VCXO supplier for major telecommunication companies. In the following years, Taitien invested significant resources into R&D, becoming one of the leading producers of surface mount oscillators with CMOS and LVPECL outputs. To this day, Taitien continues to operate as a top tier manufacturer in the FCP industry, offering leading edge solutions to its customers worldwide.


Part Number

Manufacturer

Description

Unit Price

In Stock

TTEAALJANF-50.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 50MHz
Function : -
Output : CMOS
Voltage - Supply : 3.3V
Frequency Stability : ±500ppb
Absolute Pull Range (APR) : -
Operating Temperature : -40°C ~ 85°C
Current - Supply (Max) : 6mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

221 in stock

TTEAALSANF-10.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 10MHz
Function : -
Output : Clipped Sine Wave
Voltage - Supply : 3.3V
Frequency Stability : ±500ppb
Absolute Pull Range (APR) : -
Operating Temperature : -40°C ~ 85°C
Current - Supply (Max) : 3.5mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

193 in stock

TTEAALSANF-20.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 20MHz
Function : -
Output : Clipped Sine Wave
Voltage - Supply : 3.3V
Frequency Stability : ±500ppb
Absolute Pull Range (APR) : -
Operating Temperature : -40°C ~ 85°C
Current - Supply (Max) : 3.5mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

47 in stock

TTEAALSANF-26.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 26MHz
Function : -
Output : Clipped Sine Wave
Voltage - Supply : 3.3V
Frequency Stability : ±500ppb
Absolute Pull Range (APR) : -
Operating Temperature : -40°C ~ 85°C
Current - Supply (Max) : 3.5mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

32 in stock

TTEAALSANF-50.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 50MHz
Function : -
Output : Clipped Sine Wave
Voltage - Supply : 3.3V
Frequency Stability : ±500ppb
Absolute Pull Range (APR) : -
Operating Temperature : -40°C ~ 85°C
Current - Supply (Max) : 3.5mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

85 in stock

TTEABLJANF-10.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 10MHz
Function : -
Output : CMOS
Voltage - Supply : 3.3V
Frequency Stability : ±1ppm
Absolute Pull Range (APR) : -
Operating Temperature : -40°C ~ 85°C
Current - Supply (Max) : 6mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

124 in stock

TTEAKLJANF-10.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 10MHz
Function : -
Output : CMOS
Voltage - Supply : 3.3V
Frequency Stability : ±280ppb
Absolute Pull Range (APR) : -
Operating Temperature : -40°C ~ 85°C
Current - Supply (Max) : 6mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

118 in stock

TTEAMCJANF-40.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 40MHz
Function : -
Output : CMOS
Voltage - Supply : 3.3V
Frequency Stability : ±100ppb
Absolute Pull Range (APR) : -
Operating Temperature : -20°C ~ 70°C
Current - Supply (Max) : 6mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

174 in stock

TTEAMCSANF-10.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 10MHz
Function : -
Output : Clipped Sine Wave
Voltage - Supply : 3.3V
Frequency Stability : ±100ppb
Absolute Pull Range (APR) : -
Operating Temperature : -20°C ~ 70°C
Current - Supply (Max) : 3.5mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

473 in stock

TTEATCJANF-20.480000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 20.48MHz
Function : -
Output : CMOS
Voltage - Supply : 3.3V
Frequency Stability : ±4.6ppm
Absolute Pull Range (APR) : -
Operating Temperature : -20°C ~ 70°C
Current - Supply (Max) : 6mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

107 in stock

TTEATLJANF-10.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 10MHz
Function : -
Output : CMOS
Voltage - Supply : 3.3V
Frequency Stability : ±4.6ppm
Absolute Pull Range (APR) : -
Operating Temperature : -40°C ~ 85°C
Current - Supply (Max) : 6mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

50 in stock

TTEATLJANF-40.000000

Taitien

Manufacturer : Taitien
Packaging : Strip
Series : TT
Part Status : Active
Base Resonator : Crystal
Type : VCTCXO
Frequency : 40MHz
Function : -
Output : CMOS
Voltage - Supply : 3.3V
Frequency Stability : ±4.6ppm
Absolute Pull Range (APR) : -
Operating Temperature : -40°C ~ 85°C
Current - Supply (Max) : 6mA
Ratings : -
Mounting Type : Surface Mount
Package / Case : 4-SMD, No Lead Exposed Pad
Size / Dimension : 0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max) : 0.083" (2.10mm)

100 in stock
