Seoul Semiconductor
- Seoul Semiconductor manufacturers and packages a wide selection of light emitting diodes (LEDs) for the automotive, lighting, appliance, mobile, signage, and back lighting units (BLU) markets. The company is the world’s fifth largest LED supplier, holding more than 10, 000 patents globally, while offering a wide range of LED technology and production capacity in areas such as "nPola", deep UV LEDs, and "Acrich", the world’s first commercially produced AC LED.
Part Number
Manufacturer
Description
Unit Price
In Stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z5-M1
Part Status : Active
Color : White, Cool
CCT (K) : 5300K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 155 lm (140 lm ~ 170 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.95V
Lumens/Watt @ Current - Test : 150 lm/W
CRI (Color Rendering Index) : 70
Current - Max : 1.5A
Viewing Angle : 118°
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
Supplier Device Package : 2-SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z5-M1
Part Status : Discontinued at
Color : White, Neutral
CCT (K) : 4000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 150 lm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.95V
Lumens/Watt @ Current - Test : 145 lm/W
CRI (Color Rendering Index) : 70
Current - Max : 1.5A
Viewing Angle : 118°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z5-M1
Part Status : Active
Color : White, Neutral
CCT (K) : 4000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 140 lm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.95V
Lumens/Watt @ Current - Test : 136 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 1.5A
Viewing Angle : 118°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z5-M1
Part Status : Discontinued at
Color : White, Neutral
CCT (K) : 4000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 140 lm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.95V
Lumens/Watt @ Current - Test : 136 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 1.5A
Viewing Angle : 118°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z5-M1
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 130 lm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.95V
Lumens/Watt @ Current - Test : 126 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 1.5A
Viewing Angle : 118°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z5-M1
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 130 lm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.95V
Lumens/Watt @ Current - Test : 126 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 1.5A
Viewing Angle : 118°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
48 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z5-M1
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 130 lm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.95V
Lumens/Watt @ Current - Test : 126 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 1.5A
Viewing Angle : 118°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SZ5-P
Part Status : Active
Color : White, Cool
CCT (K) : 6500K (6000K ~ 7000K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 130 lm (109 lm ~ 150 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.2V
Lumens/Watt @ Current - Test : 116 lm/W
CRI (Color Rendering Index) : 70 (Typ)
Current - Max : 1A
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
46914 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 112 lm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.1V
Lumens/Watt @ Current - Test : 103 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 1A
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SZ5-P
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 100 lm (91 lm ~ 109 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.2V
Lumens/Watt @ Current - Test : 89 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 1A
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z Power
Part Status : Active
Color : Amber
Wavelength : 592nm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.3V
Lumens/Watt @ Current - Test : 57 lm/W
Current - Max : 700mA
Flux @ Current/Temperature - Test : 46 lm (Typ)
Temperature - Test : 25°C
Viewing Angle : 123°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
3955 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z Power
Part Status : Discontinued at
Color : Green
Wavelength : 525nm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.3V
Lumens/Watt @ Current - Test : 87 lm/W
Current - Max : 700mA
Flux @ Current/Temperature - Test : 100 lm (Typ)
Temperature - Test : 25°C
Viewing Angle : 128°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
