Seoul Semiconductor
- Seoul Semiconductor manufacturers and packages a wide selection of light emitting diodes (LEDs) for the automotive, lighting, appliance, mobile, signage, and back lighting units (BLU) markets. The company is the world’s fifth largest LED supplier, holding more than 10, 000 patents globally, while offering a wide range of LED technology and production capacity in areas such as "nPola", deep UV LEDs, and "Acrich", the world’s first commercially produced AC LED.
Part Number
Manufacturer
Description
Unit Price
In Stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Active
Color : White, Neutral
CCT (K) : 4000K (3700K ~ 4200K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 26 lm (23 lm ~ 30 lm)
Current - Test : 65mA
Voltage - Forward (Vf) (Typ) : 3.05V
Lumens/Watt @ Current - Test : 131 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 100mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 2020 (5050 Metric)
Supplier Device Package : 5050
Size / Dimension : 0.197" L x 0.197" W (5.00mm x 5.00mm)
Height - Seated (Max) : 0.043" (1.10mm)
0
1192 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Active
Color : White, Warm
CCT (K) : 3000K (2900K ~ 3200K) (3-Step SDCM MacAdam Ellipse)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 26 lm (23 lm ~ 30 lm)
Current - Test : 65mA
Voltage - Forward (Vf) (Typ) : 3.05V
Lumens/Watt @ Current - Test : 131 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 100mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 2020 (5050 Metric)
Supplier Device Package : 5050
Size / Dimension : 0.197" L x 0.197" W (5.00mm x 5.00mm)
Height - Seated (Max) : 0.043" (1.10mm)
0
2923 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Active
Color : White, Warm
CCT (K) : 2700K (2600K ~ 3200K) (3-Step SDCM MacAdam Ellipse)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 26 lm (23 lm ~ 30 lm)
Current - Test : 65mA
Voltage - Forward (Vf) (Typ) : 3.05V
Lumens/Watt @ Current - Test : 131 lm/W
CRI (Color Rendering Index) : 80
Current - Max : 100mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 2020 (5050 Metric)
Supplier Device Package : 5050
Size / Dimension : 0.197" L x 0.197" W (5.00mm x 5.00mm)
Height - Seated (Max) : 0.043" (1.10mm)
0
497 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 3500K (3200K ~ 3700K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 33 lm (32 lm ~ 34 lm)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.15V
Lumens/Watt @ Current - Test : 105 lm/W
CRI (Color Rendering Index) : 90
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : 5630
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.037" (0.95mm)
0
47 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Active
Color : White, Warm
CCT (K) : 3000K (2900K ~ 3200K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 33 lm (32 lm ~ 34 lm)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.15V
Lumens/Watt @ Current - Test : 105 lm/W
CRI (Color Rendering Index) : 90
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : 5630
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.037" (0.95mm)
0
2796 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Warm
CCT (K) : 2700K (2600K ~ 2900K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 33 lm (32 lm ~ 34 lm)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.15V
Lumens/Watt @ Current - Test : 105 lm/W
CRI (Color Rendering Index) : 90
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : 5630
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.037" (0.95mm)
0
2033 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Acrich
Part Status : Discontinued at
Color : White, Neutral
CCT (K) : 4000K (3700K ~ 4200K)
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 31 lm (Typ)
Current - Test : 100mA
Voltage - Forward (Vf) (Typ) : 3.15V
Lumens/Watt @ Current - Test : 98 lm/W
CRI (Color Rendering Index) : 90
Current - Max : 160mA
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 4-SMD, Flat Lead Exposed Pad
Supplier Device Package : 5630
Size / Dimension : 0.205" L x 0.118" W (5.20mm x 3.00mm)
Height - Seated (Max) : 0.037" (0.95mm)
0
3190 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z Power Z5-M0
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 5300K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 142 lm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.14V
Lumens/Watt @ Current - Test : 129 lm/W
CRI (Color Rendering Index) : 70
Current - Max : 1.5A
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : 2-SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
333 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z Power Z5-M0
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 5300K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 142 lm (Typ)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 3.14V
Lumens/Watt @ Current - Test : 129 lm/W
CRI (Color Rendering Index) : 70
Current - Max : 1.5A
Viewing Angle : 120°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
980 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tape & Reel (TR)
Series : Z5-M1
Part Status : Discontinued at
Color : White, Cool
CCT (K) : 5300K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 150 lm (140 lm ~ 160 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.95V
Lumens/Watt @ Current - Test : 145 lm/W
CRI (Color Rendering Index) : 70
Current - Max : 1.5A
Viewing Angle : 118°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z5-M1
Part Status : Active
Color : White, Cool
CCT (K) : 5300K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 150 lm (140 lm ~ 160 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.95V
Lumens/Watt @ Current - Test : 145 lm/W
CRI (Color Rendering Index) : 70
Current - Max : 1.5A
Viewing Angle : 118°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
126 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : Z5-M1
Part Status : Active
Color : White, Cool
CCT (K) : 5300K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : 150 lm (140 lm ~ 160 lm)
Current - Test : 350mA
Voltage - Forward (Vf) (Typ) : 2.95V
Lumens/Watt @ Current - Test : 145 lm/W
CRI (Color Rendering Index) : 70
Current - Max : 1.5A
Viewing Angle : 118°
Mounting Type : Surface Mount
Package / Case : 1414 (3535 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.138" L x 0.138" W (3.50mm x 3.50mm)
Height - Seated (Max) : 0.085" (2.15mm)
0
75 in stock
