Samsung Semiconductor
- Samsung Semiconductor's business aims to achieve excellence as a long life, energy saving and eco-friendly light source supplier in displays and lighting applications. Samsung's advanced semiconductor manufacturing expertise serves as a strong foundation to deliver state-of-the-art LED devices. Samsung offers LED based lighting solutions in the form of back light units in display panels, exterior and dashboard lighting in automotives, lighting packages and engines with and without integrated optics, and drivers.
Part Number
Manufacturer
Description
Unit Price
In Stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Box
Series : LAM-RT30B
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1480 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 15V
Lumens/Watt @ Current - Test : 141 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 80
Viewing Angle : 145°
Features : With Connector
Size / Dimension : 216.00mm L x 273.00mm W
Height : 6.60mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LAM-RT30B
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1400 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 15.3V
Lumens/Watt @ Current - Test : 131 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 80
Viewing Angle : 145°
Features : With Connector
Size / Dimension : 216.00mm L x 273.00mm W
Height : 6.70mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LT-M552A
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1580 lm (Typ)
Current - Test : 450mA
Temperature - Test : 50°C
Voltage - Forward (Vf) (Typ) : 24.7V
Lumens/Watt @ Current - Test : 142 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 550.00mm L x 18.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LT-M562A
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1580 lm (Typ)
Current - Test : 450mA
Temperature - Test : 50°C
Voltage - Forward (Vf) (Typ) : 24.7V
Lumens/Watt @ Current - Test : 142 lm/W
Current - Max : 450mA
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 560.00mm L x 18.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
133 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LT-V562A
Part Status : Active
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1452 lm (Typ)
Current - Test : 420mA
Temperature - Test : 50°C
Voltage - Forward (Vf) (Typ) : 25.2V
Lumens/Watt @ Current - Test : 137 lm/W
Current - Max : 540mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : With Connector
Size / Dimension : 560.00mm L x 18.00mm W
Height : 5.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
173 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LT-H562D
Part Status : Active
Type : LED Module
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 2080 lm (Typ)
Current - Test : 480mA
Temperature - Test : 50°C
Voltage - Forward (Vf) (Typ) : 22.5V
Lumens/Watt @ Current - Test : 193 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : -
Features : With Connector
Size / Dimension : 560.00mm L x 18.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Box
Series : Finger-SQ30B
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1540 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 15V
Lumens/Watt @ Current - Test : 147 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 259.00mm L x 250.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : Finger-SQ30B
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1490 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 15.3V
Lumens/Watt @ Current - Test : 139 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 259.00mm L x 250.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Box
Series : Finger-RT30B
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1540 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 15V
Lumens/Watt @ Current - Test : 147 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 216.00mm L x 273.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : Finger-RT30B
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : 1490 lm (Typ)
Current - Test : 700mA
Temperature - Test : 35°C
Voltage - Forward (Vf) (Typ) : 15.3V
Lumens/Watt @ Current - Test : 139 lm/W
Current - Max : 900mA
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 216.00mm L x 273.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LT-E562A
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 4-Step MacAdam Ellipse
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1518 lm (Typ)
Current - Test : 300mA
Temperature - Test : 50°C
Voltage - Forward (Vf) (Typ) : 37.4V
Lumens/Watt @ Current - Test : 135 lm/W
Current - Max : 360mA
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : With Connector
Size / Dimension : 560.00mm L x 24.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Samsung Semiconductor
Manufacturer : Samsung Semiconductor, Inc.
Packaging : Tray
Series : LT-M272C
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Linear Light Strip
Flux @ Current/Temperature - Test : 1531 lm (Typ)
Current - Test : 450mA
Temperature - Test : 55°C
Voltage - Forward (Vf) (Typ) : 24V
Lumens/Watt @ Current - Test : 142 lm/W
Current - Max : 450mA
CRI (Color Rendering Index) : 80
Viewing Angle : 115°
Features : -
Size / Dimension : 275.00mm L x 18.00mm W
Height : 5.80mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
