PUI Audio, Inc.
- PUI Audio, Inc. is a leading developer, manufacturer and supplier of quality audio devices and components including buzzers, alerts and transducers. Corporate offices, product development, engineering, sales and customer service are located in Dayton, Ohio.
Our growth and product innovation are the results of listening to our customers. With an extensive network of sales representatives, agents and distributors, we provide products and services throughout the world.
Whether your needs are for an off-the-shelf product or a custom design, Projects Unlimited has your sound solution.
Part Number
Manufacturer
Description
Unit Price
In Stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 1.5V
Voltage Range : 1.2 ~ 1.7V
Frequency : 2.7kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 85dB @ 1.5V, 10cm
Current - Supply : 80mA
Port Location : Side
Operating Temperature : -40°C ~ 85°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.433" L x 0.551" W (11.00mm x 14.00mm)
Height - Seated (Max) : 0.138" (3.50mm)
0
1000 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 3V
Voltage Range : 3 ~ 4.5V
Frequency : 2.7kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 87dB @ 3V, 10cm
Current - Supply : 90mA
Port Location : Side
Operating Temperature : -40°C ~ 85°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.433" L x 0.551" W (11.00mm x 14.00mm)
Height - Seated (Max) : 0.138" (3.50mm)
0
3041 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 5V
Voltage Range : 4 ~ 7V
Frequency : 2.7kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 87dB @ 5V, 10cm
Current - Supply : 90mA
Port Location : Side
Operating Temperature : -40°C ~ 85°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.433" L x 0.551" W (11.00mm x 14.00mm)
Height - Seated (Max) : 0.138" (3.50mm)
0
880 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 5V
Voltage Range : 3 ~ 7V
Frequency : 2.7kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 85dB @ 5V, 10cm
Current - Supply : 80mA
Port Location : Side
Operating Temperature : -30°C ~ 60°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.433" L x 0.559" W (11.00mm x 14.20mm)
Height - Seated (Max) : 0.154" (3.90mm)
0
1544 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 5V
Voltage Range : 3 ~ 7V
Frequency : 2.7kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 85dB @ 5V, 10cm
Current - Supply : 80mA
Port Location : Top
Operating Temperature : -30°C ~ 60°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.433" L x 0.559" W (11.00mm x 14.20mm)
Height - Seated (Max) : 0.154" (3.90mm)
0
4725 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tape & Reel (TR)
Series : SMT
Part Status : Obsolete
Driver Circuitry : Transducer, Externally Driven
Input Type : -
Voltage - Rated : -
Voltage Range : -
Frequency : -
Technology : Piezo
Operating Mode : -
Duration : -
Sound Pressure Level (SPL) : -
Current - Supply : -
Port Location : -
Operating Temperature : -
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.630" L x 0.630" W (16.00mm x 16.00mm)
Height - Seated (Max) : 0.094" (2.40mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 5V
Voltage Range : 1 ~ 25V
Frequency : 4kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 75dB @ 5V, 10cm
Current - Supply : 3mA
Port Location : Side
Operating Temperature : -40°C ~ 120°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.630" L x 0.630" W (16.00mm x 16.00mm)
Height - Seated (Max) : 0.106" (2.70mm)
0
3249 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tape & Reel (TR)
Series : SMT
Part Status : Obsolete
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 5V
Voltage Range : 1 ~ 25V
Frequency : 4kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 70dB @ 5V, 10cm
Current - Supply : 3mA
Port Location : Side
Operating Temperature : -40°C ~ 120°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.630" L x 0.630" W (16.00mm x 16.00mm)
Height - Seated (Max) : 0.114" (2.90mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tray
Series : SMT
Part Status : Obsolete
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 10V
Voltage Range : 1 ~ 30V
Frequency : 2.5kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 80dB @ 10V, 10cm
Current - Supply : 8mA
Port Location : Top
Operating Temperature : -30°C ~ 85°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.866" Dia (22.00mm)
Height - Seated (Max) : 0.240" (6.10mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tray
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 10V
Voltage Range : 1 ~ 30V
Frequency : 2.5kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 80dB @ 10V, 10cm
Current - Supply : 8mA
Port Location : Top
Operating Temperature : -30°C ~ 85°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.866" Dia (22.00mm)
Height - Seated (Max) : 0.240" (6.10mm)
0
3573 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 12V
Voltage Range : 1 ~ 30V
Frequency : 4kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 90dB @ 12V, 10cm
Current - Supply : -
Port Location : Top
Operating Temperature : -30°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Custom
Termination : Solder Pads
Size / Dimension : 0.886" Dia (22.50mm)
Height - Seated (Max) : 0.287" (7.30mm)
0
635 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tape & Reel (TR)
Series : SMT
Part Status : Obsolete
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 10V
Voltage Range : 1 ~ 30V
Frequency : 4kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 90dB @ 10V, 10cm
Current - Supply : 3mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.886" Dia (22.50mm)
Height - Seated (Max) : 0.287" (7.30mm)
0
100 in stock
