PUI Audio, Inc.
- PUI Audio, Inc. is a leading developer, manufacturer and supplier of quality audio devices and components including buzzers, alerts and transducers. Corporate offices, product development, engineering, sales and customer service are located in Dayton, Ohio.
Our growth and product innovation are the results of listening to our customers. With an extensive network of sales representatives, agents and distributors, we provide products and services throughout the world.
Whether your needs are for an off-the-shelf product or a custom design, Projects Unlimited has your sound solution.
Part Number
Manufacturer
Description
Unit Price
In Stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 3V
Voltage Range : 1 ~ 25V
Frequency : 4kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 70dB @ 3V, 10cm
Current - Supply : 1mA
Port Location : Top
Operating Temperature : -30°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.354" L x 0.354" W (9.00mm x 9.00mm)
Height - Seated (Max) : 0.079" (2.00mm)
0
2596 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 5V
Voltage Range : 1 ~ 25V
Frequency : 5.2kHz
Technology : Piezo
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 70dB @ 5V, 10cm
Current - Supply : 3mA
Port Location : Top
Operating Temperature : -30°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.354" L x 0.354" W (9.00mm x 9.00mm)
Height - Seated (Max) : 0.079" (2.00mm)
0
2780 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tape & Reel (TR)
Series : SMT
Part Status : Obsolete
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 3.6V
Voltage Range : 2.5 ~ 4.5V
Frequency : 2.5kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 85dB @ 3.6V, 10cm
Current - Supply : 90mA
Port Location : Side
Operating Temperature : -30°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.335" L x 0.402" W (8.50mm x 10.20mm)
Height - Seated (Max) : 0.126" (3.20mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tape & Reel (TR)
Series : SMT
Part Status : Obsolete
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 3.6V
Voltage Range : 2.5 ~ 4.5V
Frequency : 2.7kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 87dB @ 3.6V, 10cm
Current - Supply : 90mA
Port Location : Side
Operating Temperature : -30°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.335" L x 0.402" W (8.50mm x 10.20mm)
Height - Seated (Max) : 0.126" (3.20mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 3.6V
Voltage Range : 2.5 ~ 4.5V
Frequency : 2.7kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 85dB @ 3.6V, 10cm
Current - Supply : 80mA
Port Location : Side
Operating Temperature : -20°C ~ 60°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) : 0.138" (3.50mm)
0
1842 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 3.6V
Voltage Range : 3 ~ 4.6V
Frequency : 2.83kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 93dB @ 3.6V, 10cm
Current - Supply : 100mA
Port Location : Side
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) : 0.138" (3.50mm)
0
88729 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : SMT
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 5V
Voltage Range : 4 ~ 6V
Frequency : 2.83kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 93dB @ 5V, 10cm
Current - Supply : 70mA
Port Location : Side
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
2485 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tape & Reel (TR)
Series : SMT
Part Status : Discontinued at
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 5V
Voltage Range : 5 ~ 6V
Frequency : 2.83kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 93dB @ 5V, 10cm
Current - Supply : 70mA
Port Location : Side
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tape & Reel (TR)
Series : SMT
Part Status : Obsolete
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 3.6V
Voltage Range : 3 ~ 4.6V
Frequency : 2.83kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 93dB @ 3.6V, 10cm
Current - Supply : 100mA
Port Location : Side
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 3.6V
Voltage Range : 3 ~ 4.6V
Frequency : 2.83kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 90dB @ 3.6V, 10cm
Current - Supply : 100mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) : 0.138" (3.50mm)
0
2528 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Tape & Reel (TR)
Series : SMT
Part Status : Obsolete
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 3.6V
Voltage Range : 3 ~ 4.6V
Frequency : 2.83kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 90dB @ 3.6V, 10cm
Current - Supply : 100mA
Port Location : Top
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
100 in stock
PUI Audio, Inc.
Manufacturer : PUI Audio, Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Driver Circuitry : Transducer, Externally Driven
Input Type : Peak-Peak Signal
Voltage - Rated : 3.6V
Voltage Range : 3 ~ 4.5V
Frequency : 3.5kHz
Technology : Magnetic
Operating Mode : Single Tone
Duration : -
Sound Pressure Level (SPL) : 90dB @ 3.6V, 10cm
Current - Supply : 100mA
Port Location : Side
Operating Temperature : -20°C ~ 70°C
Approvals : -
Ratings : -
Ingress Protection : -
Mounting Type : Surface Mount
Termination : Solder Pads
Size / Dimension : 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) : 0.157" (4.00mm)
0
652 in stock
