Mechatronics
- Mechatronics is a manufacturer of brushless cooling fans and thermal solutions headquartered near Seattle, WA. Mechatronics product offering includes AC axial fans, DC axial fans, AC blowers, DC blowers, AC motorized impellers and value-added assemblies. In addition to our standard products, we offer tailored solutions to fit customer specific requirements from minor modifications to fully custom products.
With factories located in Indonesia, Taiwan and China, Mechatronics offers technologically advanced products, superior quality, competitive pricing and exceptional service.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD6020
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 20.20mm
Air Flow : 16.9 CFM (0.473m鲁/min)
Static Pressure : 0.110 in H2O (27.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 27.5 dB(A)
Power (Watts) : -
RPM : 3200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.094 lb (42.64g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD6020
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 20.20mm
Air Flow : 25.8 CFM (0.722m鲁/min)
Static Pressure : 0.220 in H2O (54.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 37.0 dB(A)
Power (Watts) : -
RPM : 4900 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.094 lb (42.64g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD9238
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 92mm L x 92mm H
Width : 38.00mm
Air Flow : 110.6 CFM (3.10m鲁/min)
Static Pressure : 0.670 in H2O (166.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 55.0 dB(A)
Power (Watts) : -
RPM : 4800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.397 lb (180.08g)
0
137 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD9238
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 92mm L x 92mm H
Width : 38.00mm
Air Flow : 110.6 CFM (3.10m鲁/min)
Static Pressure : 0.670 in H2O (166.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 55.0 dB(A)
Power (Watts) : -
RPM : 4800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.397 lb (180.08g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD9238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 92mm L x 92mm H
Width : 38.00mm
Air Flow : 110.6 CFM (3.10m鲁/min)
Static Pressure : 0.670 in H2O (166.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 55.0 dB(A)
Power (Watts) : -
RPM : 4800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.397 lb (180.08g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD9238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 92mm L x 92mm H
Width : 38.00mm
Air Flow : 110.6 CFM (3.10m鲁/min)
Static Pressure : 0.670 in H2O (166.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 55.0 dB(A)
Power (Watts) : -
RPM : 4800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.397 lb (180.08g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD9238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 92mm L x 92mm H
Width : 38.00mm
Air Flow : 110.6 CFM (3.10m鲁/min)
Static Pressure : 0.670 in H2O (166.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 55.0 dB(A)
Power (Watts) : -
RPM : 4800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.397 lb (180.08g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD9238
Part Status : Active
Voltage - Rated : 36VDC
Size / Dimension : Square - 92mm L x 92mm H
Width : 38.00mm
Air Flow : 110.6 CFM (3.10m鲁/min)
Static Pressure : 0.670 in H2O (166.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 55.0 dB(A)
Power (Watts) : -
RPM : 4800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.397 lb (180.08g)
0
51 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD9238
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 92mm L x 92mm H
Width : 38.00mm
Air Flow : 100.7 CFM (2.82m鲁/min)
Static Pressure : 0.600 in H2O (149.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 53.5 dB(A)
Power (Watts) : -
RPM : 4400 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.397 lb (180.08g)
0
9 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD9238
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 92mm L x 92mm H
Width : 38.00mm
Air Flow : 100.7 CFM (2.82m鲁/min)
Static Pressure : 0.600 in H2O (149.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 53.5 dB(A)
Power (Watts) : -
RPM : 4400 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.397 lb (180.08g)
0
24 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD9238
Part Status : Active
Voltage - Rated : 48VDC
Size / Dimension : Square - 92mm L x 92mm H
Width : 38.00mm
Air Flow : 100.7 CFM (2.82m鲁/min)
Static Pressure : 0.600 in H2O (149.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 53.5 dB(A)
Power (Watts) : -
RPM : 4400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.397 lb (180.08g)
0
199 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : MD9238
Part Status : Active
Voltage - Rated : 48VDC
Size / Dimension : Square - 92mm L x 92mm H
Width : 38.00mm
Air Flow : 100.7 CFM (2.82m鲁/min)
Static Pressure : 0.600 in H2O (149.5 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 53.5 dB(A)
Power (Watts) : -
RPM : 4400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.397 lb (180.08g)
0
10 in stock
