Mechatronics
- Mechatronics is a manufacturer of brushless cooling fans and thermal solutions headquartered near Seattle, WA. Mechatronics product offering includes AC axial fans, DC axial fans, AC blowers, DC blowers, AC motorized impellers and value-added assemblies. In addition to our standard products, we offer tailored solutions to fit customer specific requirements from minor modifications to fully custom products.
With factories located in Indonesia, Taiwan and China, Mechatronics offers technologically advanced products, superior quality, competitive pricing and exceptional service.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G6015-G
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.30mm
Air Flow : 24.0 CFM (0.672m鲁/min)
Static Pressure : 0.290 in H2O (72.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 35.0 dB(A)
Power (Watts) : -
RPM : 5800 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.059 lb (26.76g)
0
14 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G6015-G
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.30mm
Air Flow : 24.0 CFM (0.672m鲁/min)
Static Pressure : 0.290 in H2O (72.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 35.0 dB(A)
Power (Watts) : -
RPM : 5800 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.059 lb (26.76g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G6015-G
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.30mm
Air Flow : 24.0 CFM (0.672m鲁/min)
Static Pressure : 0.290 in H2O (72.2 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Sensor
Noise : 35.0 dB(A)
Power (Watts) : -
RPM : 5800 RPM
Termination : 3 Wire Leads
Ingress Protection : IP57 - Dust Protected, Waterproof
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.059 lb (26.76g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G6015
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.00mm
Air Flow : 22.0 CFM (0.616m鲁/min)
Static Pressure : 0.300 in H2O (74.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 39.0 dB(A)
Power (Watts) : -
RPM : 5600 RPM
Termination : 2 Wire Leads
Ingress Protection : IP57 - Dust Protected, Waterproof
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.111 lb (50.35g)
0
38 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G6015
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 60mm L x 60mm H
Width : 15.00mm
Air Flow : 22.0 CFM (0.616m鲁/min)
Static Pressure : 0.300 in H2O (74.7 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 39.0 dB(A)
Power (Watts) : -
RPM : 5600 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.111 lb (50.35g)
0
634 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G8015-G
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 15.30mm
Air Flow : 40.0 CFM (1.12m鲁/min)
Static Pressure : 0.200 in H2O (49.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 38.0 dB(A)
Power (Watts) : -
RPM : 4400 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.128 lb (58.06g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G8015
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 15.30mm
Air Flow : 37.0 CFM (1.04m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 36.0 dB(A)
Power (Watts) : -
RPM : 4000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.128 lb (58.06g)
0
297 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G8015
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 15.30mm
Air Flow : 37.0 CFM (1.04m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 36.0 dB(A)
Power (Watts) : -
RPM : 4000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.128 lb (58.06g)
0
174 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G8015-G
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 15.30mm
Air Flow : 29.0 CFM (0.812m鲁/min)
Static Pressure : 0.110 in H2O (27.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 31.0 dB(A)
Power (Watts) : -
RPM : 3200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.128 lb (58.06g)
0
24 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G8015-G
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 15.30mm
Air Flow : 26.0 CFM (0.728m鲁/min)
Static Pressure : 0.090 in H2O (22.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 28.0 dB(A)
Power (Watts) : -
RPM : 2800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.128 lb (58.06g)
0
9 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G8015-G
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 15.30mm
Air Flow : 43.0 CFM (1.20m鲁/min)
Static Pressure : 0.230 in H2O (57.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 40.0 dB(A)
Power (Watts) : -
RPM : 4800 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.128 lb (58.06g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : G8015
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 15.30mm
Air Flow : 43.0 CFM (1.20m鲁/min)
Static Pressure : 0.230 in H2O (57.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 40.0 dB(A)
Power (Watts) : -
RPM : 4800 RPM
Termination : 2 Wire Leads
Ingress Protection : IP57 - Dust Protected, Waterproof
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.128 lb (58.06g)
0
286 in stock
