Delta Electronics
- Delta Group is the world's largest provider of switching power supplies and brushless fans, as well as a major source for power management solutions, components, visual displays, industrial automation, networking products, and renewable energy solutions. Established in 1971, Delta Group has sales offices worldwide and manufacturing plants in Taiwan, Thailand, China, Mexico and Europe. As a global leader in power electronics, Delta's mission is "To provide innovative, clean and efficient energy solutions for a better tomorrow." Delta is committed to environmental protection and has implemented green, lead-free production and recycling and waste management programs for many years.
Part Number
Manufacturer
Description
Unit Price
In Stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 35mm L x 35mm H
Width : 10.00mm
Air Flow : 5.5 CFM (0.154m鲁/min)
Static Pressure : 0.106 in H2O (26.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 22.0 dB(A)
Power (Watts) : 1.08W
RPM : 7000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.022 lb (9.98g)
0
1031 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 35mm L x 35mm H
Width : 10.00mm
Air Flow : 5.5 CFM (0.154m鲁/min)
Static Pressure : 0.106 in H2O (26.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 22.0 dB(A)
Power (Watts) : 1.08W
RPM : 7000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.022 lb (9.98g)
0
360 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 35mm L x 35mm H
Width : 10.00mm
Air Flow : 5.5 CFM (0.154m鲁/min)
Static Pressure : 0.106 in H2O (26.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Sensor
Noise : 22.0 dB(A)
Power (Watts) : 1.08W
RPM : 7000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.022 lb (9.98g)
0
560 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 35mm L x 35mm H
Width : 10.00mm
Air Flow : 3.4 CFM (0.095m鲁/min)
Static Pressure : 0.050 in H2O (12.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 15.0 dB(A)
Power (Watts) : 480mW
RPM : 4500 RPM
Termination : -
Ingress Protection : -
Operating Temperature : -
Approvals : -
Weight : -
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 35mm L x 35mm H
Width : 10.00mm
Air Flow : 4.5 CFM (0.126m鲁/min)
Static Pressure : 0.075 in H2O (18.6 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 18.0 dB(A)
Power (Watts) : 600mW
RPM : 5800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.022 lb (9.98g)
0
20 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.00mm
Air Flow : 6.9 CFM (0.193m鲁/min)
Static Pressure : 0.140 in H2O (34.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection
Noise : 27.0 dB(A)
Power (Watts) : 350mW
RPM : 6000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UR, VDE
Weight : 0.031 lb (14.06g)
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.00mm
Air Flow : 8.2 CFM (0.230m鲁/min)
Static Pressure : 0.190 in H2O (47.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 31.5 dB(A)
Power (Watts) : 450mW
RPM : 7000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.031 lb (14.06g)
0
59 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.00mm
Air Flow : 8.2 CFM (0.230m鲁/min)
Static Pressure : 0.190 in H2O (47.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 31.5 dB(A)
Power (Watts) : 450mW
RPM : 7000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.031 lb (14.06g)
0
100 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.00mm
Air Flow : 4.4 CFM (0.123m鲁/min)
Static Pressure : 0.068 in H2O (17.0 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 16.0 dB(A)
Power (Watts) : 150mW
RPM : 4000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.031 lb (14.06g)
0
1511 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.00mm
Air Flow : 5.7 CFM (0.160m鲁/min)
Static Pressure : 0.104 in H2O (26.0 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 21.5 dB(A)
Power (Watts) : 250mW
RPM : 5000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.031 lb (14.06g)
0
654 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 15.00mm
Air Flow : 8.1 CFM (0.227m鲁/min)
Static Pressure : 0.202 in H2O (50.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Sensor
Noise : 24.5 dB(A)
Power (Watts) : 850mW
RPM : 6000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UL, VDE
Weight : 0.055 lb (24.95g)
0
239 in stock
Delta Electronics
Manufacturer : Delta Electronics
Series : AFB
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 40mm L x 40mm H
Width : 10.00mm
Air Flow : 9.3 CFM (0.260m鲁/min)
Static Pressure : 0.242 in H2O (60.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Protection
Noise : 35.5 dB(A)
Power (Watts) : 550mW
RPM : 8000 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : 14 ~ 158°F (-10 ~ 70°C)
Approvals : CE, CSA, UR, VDE
Weight : 0.031 lb (14.06g)
0
100 in stock
