Central Semiconductor
- Since 1974, Central Semiconductor has manufactured innovative discrete semiconductors used in electronic products worldwide. Devices currently include standard and custom small signal transistors, bipolar power transistors, MOSFETs, diodes, rectifiers, protection devices, current limiting diodes, bridge rectifiers, thyristors, and silicon carbide devices. Central’s devices are available in industry standard surface mount and through-hole packages, bare die, TLMs (Tiny Leadless Modules™), and MDMs (Multi Discrete Modules™). Central has earned a reputation as a manufacturer of the highest quality products consistently delivered on-time, and a provider of exceptional value-added services.
Part Number
Manufacturer
Description
Unit Price
In Stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
FET Type : N-Channel
Technology : MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) : 20V
Current - Continuous Drain (Id) @ 25°C : 650mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) : 1.5V, 4.5V
Rds On (Max) @ Id, Vgs : 230 mOhm @ 600mA, 4.5V
Vgs(th) (Max) @ Id : 1.1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : 1.58nC @ 4.5V
Vgs (Max) : 8V
Input Capacitance (Ciss) (Max) @ Vds : 100pF @ 16V
FET Feature : -
Power Dissipation (Max) : 300mW (Ta)
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Supplier Device Package : SOT-523
Package / Case : SOT-523
0
4706 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
FET Type : P-Channel
Technology : MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) : 20V
Current - Continuous Drain (Id) @ 25°C : 100mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) : 1.5V, 4V
Rds On (Max) @ Id, Vgs : 8 Ohm @ 10mA, 4V
Vgs(th) (Max) @ Id : 1.1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : 0.66nC @ 4.5V
Vgs (Max) : 10V
Input Capacitance (Ciss) (Max) @ Vds : 45pF @ 3V
FET Feature : -
Power Dissipation (Max) : 250mW (Ta)
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Supplier Device Package : SOT-523
Package / Case : SOT-523
0
5800 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
FET Type : P-Channel
Technology : MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) : 30V
Current - Continuous Drain (Id) @ 25°C : 450mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) : 1.8V, 4.5V
Rds On (Max) @ Id, Vgs : 1.1 Ohm @ 430mA, 4.5V
Vgs(th) (Max) @ Id : 1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : 0.88nC @ 4.5V
Vgs (Max) : 8V
Input Capacitance (Ciss) (Max) @ Vds : 55pF @ 25V
FET Feature : -
Power Dissipation (Max) : 250mW (Ta)
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Supplier Device Package : SOT-523
Package / Case : SOT-523
0
4215 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
FET Type : P-Channel
Technology : MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) : 20V
Current - Continuous Drain (Id) @ 25°C : 650mA (Ta)
Drive Voltage (Max Rds On, Min Rds On) : 1.8V, 4.5V
Rds On (Max) @ Id, Vgs : 360 mOhm @ 350mA, 4.5V
Vgs(th) (Max) @ Id : 1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : 1.2nC @ 4.5V
Vgs (Max) : 8V
Input Capacitance (Ciss) (Max) @ Vds : 100pF @ 16V
FET Feature : -
Power Dissipation (Max) : 300mW (Ta)
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Supplier Device Package : SOT-523
Package / Case : SOT-523
0
2236 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) : 500mA
Voltage - Forward (Vf) (Max) @ If : 470mV @ 500mA
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 20µA @ 10V
Capacitance @ Vr, F : 50pF @ 1V, 1MHz
Mounting Type : Surface Mount
Package / Case : SC-89, SOT-490
Supplier Device Package : SOT-523
Operating Temperature - Junction : -65°C ~ 150°C
0
5401 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) : 200mA
Voltage - Forward (Vf) (Max) @ If : 750mV @ 100mA
Speed : Small Signal =
5ns
500nA @ 25V
10pF @ 1V, 1MHz
Surface Mount
SC-89, SOT-490
SOT-523
-65°C ~ 150°C
Reverse Recovery Time (trr) : 5ns
Current - Reverse Leakage @ Vr : 500nA @ 25V
Capacitance @ Vr, F : 10pF @ 1V, 1MHz
Mounting Type : Surface Mount
Package / Case : SC-89, SOT-490
Supplier Device Package : SOT-523
Operating Temperature - Junction : -65°C ~ 150°C
0
5955 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Configuration : 1 Pair Common Anode
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) (per Diode) : 200mA
Voltage - Forward (Vf) (Max) @ If : 750mV @ 100mA
Speed : Small Signal =
5ns
500nA @ 25V
-65°C ~ 150°C
Surface Mount
SC-89, SOT-490
SOT-523
Reverse Recovery Time (trr) : 5ns
Current - Reverse Leakage @ Vr : 500nA @ 25V
Operating Temperature - Junction : -65°C ~ 150°C
Mounting Type : Surface Mount
Package / Case : SC-89, SOT-490
Supplier Device Package : SOT-523
0
5995 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Configuration : 1 Pair Series Connection
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 40V
Current - Average Rectified (Io) (per Diode) : 200mA
Voltage - Forward (Vf) (Max) @ If : 750mV @ 100mA
Speed : Small Signal =
5ns
500nA @ 25V
-65°C ~ 150°C
Surface Mount
SC-89, SOT-490
SOT-523
Reverse Recovery Time (trr) : 5ns
Current - Reverse Leakage @ Vr : 500nA @ 25V
Operating Temperature - Junction : -65°C ~ 150°C
Mounting Type : Surface Mount
Package / Case : SC-89, SOT-490
Supplier Device Package : SOT-523
0
10151 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Transistor Type : NPN
Current - Collector (Ic) (Max) : 600mA
Voltage - Collector Emitter Breakdown (Max) : 40V
Vce Saturation (Max) @ Ib, Ic : 1V @ 50mA, 500mA
Current - Collector Cutoff (Max) : 10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 100 @ 150mA, 10V
Power - Max : 250mW
Frequency - Transition : 300MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : SC-89, SOT-490
Supplier Device Package : SOT-523
0
3000 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Transistor Type : PNP
Current - Collector (Ic) (Max) : 600mA
Voltage - Collector Emitter Breakdown (Max) : 60V
Vce Saturation (Max) @ Ib, Ic : 1.6V @ 50mA, 500mA
Current - Collector Cutoff (Max) : 10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 100 @ 150mA, 10V
Power - Max : 250mW
Frequency - Transition : 200MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : SC-89, SOT-490
Supplier Device Package : SOT-523
0
3690 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Transistor Type : NPN
Current - Collector (Ic) (Max) : 200mA
Voltage - Collector Emitter Breakdown (Max) : 40V
Vce Saturation (Max) @ Ib, Ic : 300mV @ 5mA, 50mA
Current - Collector Cutoff (Max) : -
DC Current Gain (hFE) (Min) @ Ic, Vce : 100 @ 10mA, 1V
Power - Max : 250mW
Frequency - Transition : 300MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : SC-89, SOT-490
Supplier Device Package : SOT-523
0
1846 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Transistor Type : PNP
Current - Collector (Ic) (Max) : 100mA
Voltage - Collector Emitter Breakdown (Max) : 50V
Vce Saturation (Max) @ Ib, Ic : 225mV @ 10mA, 100mA
Current - Collector Cutoff (Max) : 50nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce : 390 @ 100µA, 5V
Power - Max : 350mW
Frequency - Transition : 100MHz
Operating Temperature : -65°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Package / Case : SC-89, SOT-490
Supplier Device Package : SOT-523
0
5225 in stock
