Central Semiconductor
- Since 1974, Central Semiconductor has manufactured innovative discrete semiconductors used in electronic products worldwide. Devices currently include standard and custom small signal transistors, bipolar power transistors, MOSFETs, diodes, rectifiers, protection devices, current limiting diodes, bridge rectifiers, thyristors, and silicon carbide devices. Central’s devices are available in industry standard surface mount and through-hole packages, bare die, TLMs (Tiny Leadless Modules™), and MDMs (Multi Discrete Modules™). Central has earned a reputation as a manufacturer of the highest quality products consistently delivered on-time, and a provider of exceptional value-added services.
Part Number
Manufacturer
Description
Unit Price
In Stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 70V
Current - Average Rectified (Io) : 15mA
Voltage - Forward (Vf) (Max) @ If : 410mV @ 1mA
Speed : Small Signal =
-
200nA @ 50V
2pF @ 0V, 1MHz
Surface Mount
TO-236-3, SC-59, SOT-23-3
SOT-23
-65°C ~ 150°C
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 200nA @ 50V
Capacitance @ Vr, F : 2pF @ 0V, 1MHz
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
Operating Temperature - Junction : -65°C ~ 150°C
0
4166 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Configuration : 1 Pair Common Anode
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 70V
Current - Average Rectified (Io) (per Diode) : 15mA
Voltage - Forward (Vf) (Max) @ If : 410mV @ 1mA
Speed : Small Signal =
-
200nA @ 50V
-65°C ~ 150°C
Surface Mount
TO-236-3, SC-59, SOT-23-3
SOT-23
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 200nA @ 50V
Operating Temperature - Junction : -65°C ~ 150°C
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
0
5331 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Configuration : 1 Pair Common Cathode
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 70V
Current - Average Rectified (Io) (per Diode) : 15mA
Voltage - Forward (Vf) (Max) @ If : 410mV @ 1mA
Speed : Small Signal =
-
200nA @ 50V
-65°C ~ 150°C
Surface Mount
TO-236-3, SC-59, SOT-23-3
SOT-23
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 200nA @ 50V
Operating Temperature - Junction : -65°C ~ 150°C
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
0
5914 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Configuration : 1 Pair Series Connection
Diode Type : Schottky
Voltage - DC Reverse (Vr) (Max) : 70V
Current - Average Rectified (Io) (per Diode) : 15mA
Voltage - Forward (Vf) (Max) @ If : 410mV @ 1mA
Speed : Small Signal =
-
200nA @ 50V
-65°C ~ 150°C
Surface Mount
TO-236-3, SC-59, SOT-23-3
SOT-23
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 200nA @ 50V
Operating Temperature - Junction : -65°C ~ 150°C
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
0
31588 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Configuration : 1 Pair Series Connection
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 100V
Current - Average Rectified (Io) (per Diode) : 200mA
Voltage - Forward (Vf) (Max) @ If : 1.1V @ 100mA
Speed : Small Signal =
4ns
500nA @ 100V
-65°C ~ 150°C
Surface Mount
TO-236-3, SC-59, SOT-23-3
SOT-23
Reverse Recovery Time (trr) : 4ns
Current - Reverse Leakage @ Vr : 500nA @ 100V
Operating Temperature - Junction : -65°C ~ 150°C
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
0
12652 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Configuration : 1 Pair Series Connection
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 120V
Current - Average Rectified (Io) (per Diode) : 200mA
Voltage - Forward (Vf) (Max) @ If : 1V @ 100mA
Speed : Small Signal =
4ns
300nA @ 50V
-65°C ~ 150°C
Surface Mount
TO-236-3, SC-59, SOT-23-3
SOT-23
Reverse Recovery Time (trr) : 4ns
Current - Reverse Leakage @ Vr : 300nA @ 50V
Operating Temperature - Junction : -65°C ~ 150°C
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
0
3513 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 75V
Current - Average Rectified (Io) : 250mA
Voltage - Forward (Vf) (Max) @ If : 1V @ 10mA
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 4ns
Current - Reverse Leakage @ Vr : 25nA @ 20V
Capacitance @ Vr, F : 4pF @ 0V, 1MHz
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
Operating Temperature - Junction : -65°C ~ 150°C
0
58690 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 75V
Current - Average Rectified (Io) : 250mA
Voltage - Forward (Vf) (Max) @ If : 970mV @ 100mA
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : 4ns
Current - Reverse Leakage @ Vr : 100µA @ 150V
Capacitance @ Vr, F : 2pF @ 0V, 1MHz
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
Operating Temperature - Junction : -65°C ~ 150°C
0
15450 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : -
Series : -
Part Status : Obsolete
FET Type : P-Channel
Technology : MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) : 20V
Current - Continuous Drain (Id) @ 25°C : 2.3A (Ta)
Drive Voltage (Max Rds On, Min Rds On) : 2.5V, 5V
Rds On (Max) @ Id, Vgs : 88 mOhm @ 1.2A, 5V
Vgs(th) (Max) @ Id : 1.4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : 12nC @ 5V
Vgs (Max) : 12V
Input Capacitance (Ciss) (Max) @ Vds : 800pF @ 10V
FET Feature : -
Power Dissipation (Max) : 350mW (Ta)
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Supplier Device Package : SOT-23F
Package / Case : SOT-23-3 Flat Leads
0
100 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tape & Reel (TR)
Alternate Packaging
Series : -
Part Status : Obsolete
FET Type : P-Channel
Technology : MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) : 20V
Current - Continuous Drain (Id) @ 25°C : 2.3A (Ta)
Drive Voltage (Max Rds On, Min Rds On) : 2.5V, 5V
Rds On (Max) @ Id, Vgs : 88 mOhm @ 1.2A, 5V
Vgs(th) (Max) @ Id : 1.4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : 12nC @ 5V
Vgs (Max) : 12V
Input Capacitance (Ciss) (Max) @ Vds : 800pF @ 10V
FET Feature : -
Power Dissipation (Max) : 350mW (Ta)
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Supplier Device Package : SOT-23F
Package / Case : SOT-23-3 Flat Leads
0
33000 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : -
Series : -
Part Status : Obsolete
FET Type : N-Channel
Technology : MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) : 20V
Current - Continuous Drain (Id) @ 25°C : 3.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On) : 2.5V, 4.5V
Rds On (Max) @ Id, Vgs : 50 mOhm @ 1.6A, 4.5V
Vgs(th) (Max) @ Id : 1.2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : 10nC @ 4.5V
Vgs (Max) : 12V
Input Capacitance (Ciss) (Max) @ Vds : 395pF @ 10V
FET Feature : -
Power Dissipation (Max) : 350mW (Ta)
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Supplier Device Package : SOT-23F
Package / Case : SOT-23-3 Flat Leads
0
100 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Tape & Reel (TR)
Alternate Packaging
Series : -
Part Status : Obsolete
FET Type : N-Channel
Technology : MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) : 20V
Current - Continuous Drain (Id) @ 25°C : 3.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On) : 2.5V, 4.5V
Rds On (Max) @ Id, Vgs : 50 mOhm @ 1.6A, 4.5V
Vgs(th) (Max) @ Id : 1.2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs : 10nC @ 4.5V
Vgs (Max) : 12V
Input Capacitance (Ciss) (Max) @ Vds : 395pF @ 10V
FET Feature : -
Power Dissipation (Max) : 350mW (Ta)
Operating Temperature : -55°C ~ 150°C (TJ)
Mounting Type : Surface Mount
Supplier Device Package : SOT-23F
Package / Case : SOT-23-3 Flat Leads
0
18000 in stock
