Wurth Electronics
- Wurth Electronics eiSos GmbH & Co. KG is a manufacturer of electronic and electromechanical components for the electronics industry. Production sites in Europe, Asia and North America supply a growing number of customers worldwide. The product program encompasses EMC components, inductors, transformers, HF components, varistors, capacitors, power modules, LEDs, plug connectors, power supply elements, wireless power coils, switches, connection technology and fuse holders. Wurth Electronic eiSos GmbH & Co. KG, together with its specialized affiliated companies, form the Wurth Electronic eiSos Group.
Wurth Electronics eiSos GmbH & Co. KG (Focus: standard components), Wurth Electronics iBE GmbH (Focus: customized passive components for the automotive industry), Wurth Electronics Midcom Inc. (Focus: transformers and custom magnetics), Wurth Electronics Stelvio Kontek S.p.A. (Focus: customized plug connectors), AMBER wireless GmbH (Focus: wireless data transmission solutions) and IQD Frequency Products Ltd (Focus: frequency-control components) form the Wurth Electronics eiSos Group. The group of companies with 6,700 employees generated sales of approx. € 653 million in 2017. The Wurth Electronics eiSos Group is one of the biggest European manufacturers of passive components and operates in 50 countries.
Through its technology partnership with the Audi Sport ABT Schaeffler Formula E Team and its support for the Formula E racing series, the Group demonstrates its innovative strength in eMobility. Other global growth markets, such as Energy Harvesting, Internet of Things and Wireless Communication, are addressed with innovative products.
The Wurth Electronics eiSos Group is part of the Wurth Group, the world market leader for assembly and fastening technology.
Part Number
Manufacturer
Description
Unit Price
In Stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SIMW
Part Status : Active
Type : Infrared (IR)
Current - DC Forward (If) (Max) : 1A
Radiant Intensity (Ie) Min @ If : 250mW/sr @ 1A (Typ)
Wavelength : 855nm
Voltage - Forward (Vf) (Typ) : 2.2V
Viewing Angle : 130°
Orientation : Top View
Operating Temperature : -40°C ~ 85°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
2026 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SIMW
Part Status : Active
Type : Infrared (IR)
Current - DC Forward (If) (Max) : 1A
Radiant Intensity (Ie) Min @ If : 300mW/sr @ 1A (Typ)
Wavelength : 945nm
Voltage - Forward (Vf) (Typ) : 1.9V
Viewing Angle : 90°
Orientation : Top View
Operating Temperature : -40°C ~ 85°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
829 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SIMW
Part Status : Active
Type : Infrared (IR)
Current - DC Forward (If) (Max) : 1A
Radiant Intensity (Ie) Min @ If : 220mW/sr @ 1A (Typ)
Wavelength : 945nm
Voltage - Forward (Vf) (Typ) : 1.9V
Viewing Angle : 130°
Orientation : Top View
Operating Temperature : -40°C ~ 85°C (TA)
Mounting Type : Surface Mount
Package / Case : 2-SMD, No Lead Exposed Pad
0
1478 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SMSW
Part Status : Active
Color : Blue
Configuration : Standard
Lens Color : Colorless
Lens Transparency : Clear
Millicandela Rating : 150mcd
Lens Style : Rectangle with Domed Top
Lens Size : 2.00mm x 1.00mm
Voltage - Forward (Vf) (Typ) : 3.4V
Current - Test : 20mA
Viewing Angle : 120°
Mounting Type : Surface Mount, Right Angle
Wavelength - Dominant : 470nm
Wavelength - Peak : 468nm
Features : -
Package / Case : 2-SMD, Side View
Supplier Device Package : 1204
Size / Dimension : 3.20mm L x 1.50mm W
Height (Max) : 1.20mm
0
2288 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SMSW
Part Status : Active
Color : Blue
Configuration : Standard
Lens Color : Colorless
Lens Transparency : Clear
Millicandela Rating : 120mcd
Lens Style : Rectangle with Domed Top
Lens Size : 2.00mm x 1.00mm
Voltage - Forward (Vf) (Typ) : 3.2V
Current - Test : 20mA
Viewing Angle : 120°
Mounting Type : Surface Mount, Right Angle
Wavelength - Dominant : 470nm
Wavelength - Peak : 465nm
Features : -
Package / Case : 2-SMD, No Lead
Supplier Device Package : 1206
Size / Dimension : 3.20mm L x 1.50mm W
Height (Max) : 1.10mm
0
5828 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SMSW
Part Status : Active
Color : Green
Configuration : Standard
Lens Color : Colorless
Lens Transparency : Clear
Millicandela Rating : 600mcd
Lens Style : Rectangle with Domed Top
Lens Size : 2.00mm x 1.00mm
Voltage - Forward (Vf) (Typ) : 3.3V
Current - Test : 20mA
Viewing Angle : 120°
Mounting Type : Surface Mount, Right Angle
Wavelength - Dominant : 525nm
Wavelength - Peak : 520nm
Features : -
Package / Case : 2-SMD, Side View
Supplier Device Package : 1204
Size / Dimension : 3.20mm L x 1.50mm W
Height (Max) : 1.20mm
0
8354 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SMSW
Part Status : Active
Color : Green
Configuration : Standard
Lens Color : Colorless
Lens Transparency : Clear
Millicandela Rating : 250mcd
Lens Style : Rectangle with Domed Top
Lens Size : 2.00mm x 1.00mm
Voltage - Forward (Vf) (Typ) : 3.3V
Current - Test : 20mA
Viewing Angle : 120°
Mounting Type : Surface Mount, Right Angle
Wavelength - Dominant : 525nm
Wavelength - Peak : 520nm
Features : -
Package / Case : 2-SMD, No Lead
Supplier Device Package : 1206
Size / Dimension : 3.20mm L x 1.50mm W
Height (Max) : 1.10mm
0
5908 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SFSW
Part Status : Active
Color : Red, Green, Blue (RGB)
Configuration : Common Anode
Lens Color : Colorless
Lens Transparency : Clear
Millicandela Rating : 450mcd Red, 850mcd Green, 140mcd Blue
Lens Style : Rectangle with Domed Top
Lens Size : 2.00mm x 1.00mm
Voltage - Forward (Vf) (Typ) : 2V Red, 2.8V Green, 3V Blue
Current - Test : 20mA Red, 20mA Green, 20mA Blue
Viewing Angle : 120°, 100°
Mounting Type : Surface Mount, Right Angle
Wavelength - Dominant : 622nm Red, 523nm Green, 465nm Blue
Wavelength - Peak : 632nm Red, 515nm Green, 460nm Blue
Features : -
Package / Case : 4-SMD, No Lead
Supplier Device Package : 1204
Size / Dimension : 3.20mm L x 1.50mm W
Height (Max) : 1.00mm
0
1792 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SFSW
Part Status : Active
Color : Red, Green, Blue (RGB)
Configuration : Common Anode
Lens Color : Colorless
Lens Transparency : Clear
Millicandela Rating : 200mcd Red, 500mcd Green, 150mcd Blue
Lens Style : Rectangle with Domed Top
Lens Size : 2.00mm x 1.00mm
Voltage - Forward (Vf) (Typ) : 2V Red, 3V Green, 3.1V Blue
Current - Test : 20mA Red, 20mA Green, 20mA Blue
Viewing Angle : 120°, 100°
Mounting Type : Surface Mount, Right Angle
Wavelength - Dominant : 622nm Red, 523nm Green, 470nm Blue
Wavelength - Peak : 632nm Red, 515nm Green, 465nm Blue
Features : -
Package / Case : 4-SMD, No Lead
Supplier Device Package : 1204
Size / Dimension : 3.20mm L x 1.48mm W
Height (Max) : 1.10mm
0
3824 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SBSW
Part Status : Active
Color : Green, Red
Configuration : Common Anode
Lens Color : Colorless
Lens Transparency : Clear
Millicandela Rating : 160mcd Green, 60mcd Red
Lens Style : Rectangle with Domed Top
Lens Size : 2.20mm x 1.00mm
Voltage - Forward (Vf) (Typ) : 3.3V Green, 2V Red
Current - Test : 20mA Green, 20mA Red
Viewing Angle : 120°
Mounting Type : Surface Mount, Right Angle
Wavelength - Dominant : 525nm Green, 624nm Red
Wavelength - Peak : 520nm Green, 632nm Red
Features : -
Package / Case : 2-SMD, Side View
Supplier Device Package : 2-SMD
Size / Dimension : 3.20mm L x 1.50mm W
Height (Max) : 1.00mm
0
3699 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SMSW
Part Status : Active
Color : Red
Configuration : Standard
Lens Color : Colorless
Lens Transparency : Clear
Millicandela Rating : 130mcd
Lens Style : Rectangle with Domed Top
Lens Size : 2.00mm x 1.00mm
Voltage - Forward (Vf) (Typ) : 2V
Current - Test : 20mA
Viewing Angle : 120°
Mounting Type : Surface Mount, Right Angle
Wavelength - Dominant : 624nm
Wavelength - Peak : 632nm
Features : -
Package / Case : 2-SMD, Side View
Supplier Device Package : 1204
Size / Dimension : 3.20mm L x 1.50mm W
Height (Max) : 1.20mm
0
7373 in stock
Wurth Electronics
Manufacturer : Wurth Electronics Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : WL-SMSW
Part Status : Active
Color : Red
Configuration : Standard
Lens Color : Colorless
Lens Transparency : Clear
Millicandela Rating : 70mcd
Lens Style : Rectangle with Domed Top
Lens Size : 2.00mm x 1.00mm
Voltage - Forward (Vf) (Typ) : 2V
Current - Test : 20mA
Viewing Angle : 120°
Mounting Type : Surface Mount, Right Angle
Wavelength - Dominant : 624nm
Wavelength - Peak : 632nm
Features : -
Package / Case : 2-SMD, No Lead
Supplier Device Package : 1206
Size / Dimension : 3.20mm L x 1.50mm W
Height (Max) : 1.10mm
0
5743 in stock
