TT Electronics/Optek Technology
- Optek Technology designs and manufactures electronic components for customers across defense and aerospace, medical, transportation, energy and industrial electronics markets.
Key applications are sensing, illumination and indication in office equipment, encoders, military and Hi-Rel applications, and medical diagnostic equipment.
Products include: optoelectronics – discrete LEDs, surface mount and thru-hole LEDs and Hall effect sensors.
Part Number
Manufacturer
Description
Unit Price
In Stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Packaging : Bulk
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 50000VDC
Current Transfer Ratio (Min) : 10% @ 10mA
Current Transfer Ratio (Max) : -
Turn On / Turn Off Time (Typ) : 120µs, 70µs
Rise / Fall Time (Typ) : -
Input Type : DC
Output Type : Transistor with Base
Voltage - Output (Max) : 30V
Current - Output / Channel : 25mA
Voltage - Forward (Vf) (Typ) : 1.3V
Current - DC Forward (If) (Max) : 50mA
Vce Saturation (Max) : 500mV
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : Axial - 5 leads
Supplier Device Package : Axial
0
95 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Packaging : Bulk
Series : -
Part Status : Active
Number of Channels : 1
Inputs - Side 1/Side 2 : 1/0
Voltage - Isolation : 50000VDC
Common Mode Transient Immunity (Min) : -
Input Type : DC
Output Type : Open Collector, Schottky Clamped
Current - Output / Channel : 25mA
Data Rate : 5Mbps
Propagation Delay tpLH / tpHL (Max) : 70ns, 120ns
Rise / Fall Time (Typ) : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Voltage - Supply : 7V
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : -
Supplier Device Package : -
0
131 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 6000VDC
Current Transfer Ratio (Min) : 20% @ 10mA
Current Transfer Ratio (Max) : -
Turn On / Turn Off Time (Typ) : 4µs, 3µs
Rise / Fall Time (Typ) : -
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 30V
Current - Output / Channel : -
Voltage - Forward (Vf) (Typ) : 1.2V
Current - DC Forward (If) (Max) : 50mA
Vce Saturation (Max) : 400mV
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 4-DIP (0.300", 7.62mm)
Supplier Device Package : 4-DIP
0
960 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Packaging : Tube
Series : -
Part Status : Active
Number of Channels : 1
Voltage - Isolation : 6000VDC
Current Transfer Ratio (Min) : 100% @ 10mA
Current Transfer Ratio (Max) : -
Turn On / Turn Off Time (Typ) : 4µs, 3µs
Rise / Fall Time (Typ) : -
Input Type : DC
Output Type : Transistor
Voltage - Output (Max) : 30V
Current - Output / Channel : -
Voltage - Forward (Vf) (Typ) : 1.2V (Max)
Current - DC Forward (If) (Max) : 50mA
Vce Saturation (Max) : 400mV
Operating Temperature : -40°C ~ 85°C
Mounting Type : Through Hole
Package / Case : 4-DIP (0.300", 7.62mm)
Supplier Device Package : 4-DIP
0
242 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Series : Photologic®
Part Status : Active
Wavelength : 935nm
Type : Photo Detector, Logic Output
Output Type : Open Collector
Package / Case : 3-SIP, Side View
Operating Temperature : -40°C ~ 85°C (TA)
0
975 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Series : Photologic®
Part Status : Obsolete
Wavelength : 935nm
Type : Photo Detector, Logic Output
Output Type : Open Collector
Package / Case : 3-SIP, Side View
Operating Temperature : -40°C ~ 85°C (TA)
0
100 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Series : Photologic®
Part Status : Obsolete
Wavelength : 935nm
Type : Photo Detector, Logic Output
Output Type : Open Collector
Package / Case : 3-SIP, Side View
Operating Temperature : -40°C ~ 85°C (TA)
0
100 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Series : Photologic®
Part Status : Active
Wavelength : 935nm
Type : Photo Detector, Logic Output
Output Type : Open Collector
Package / Case : 3-SIP, Side View
Operating Temperature : -40°C ~ 85°C (TA)
0
134 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Series : Photologic®
Part Status : Obsolete
Wavelength : 935nm
Type : Photo Detector, Logic Output
Output Type : Open Collector
Package / Case : 3-SIP, Side View
Operating Temperature : -40°C ~ 85°C (TA)
0
100 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Series : Photologic®
Part Status : Obsolete
Wavelength : 935nm
Type : Photo Detector, Logic Output
Output Type : Open Collector
Package / Case : 3-SIP, Side View
Operating Temperature : -40°C ~ 85°C (TA)
0
100 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Series : Photologic®
Part Status : Obsolete
Wavelength : 935nm
Type : Photo Detector, Logic Output
Output Type : Open Collector Inverter
Package / Case : 3-SIP, Side View
Operating Temperature : -40°C ~ 85°C (TA)
0
100 in stock
Optek Technology / TT Electronics
Manufacturer : TT Electronics/Optek Technology
Series : Photologic®
Part Status : Obsolete
Wavelength : 935nm
Type : Photo Detector, Logic Output
Output Type : Open Collector Inverter
Package / Case : 3-SIP, Side View
Operating Temperature : -40°C ~ 85°C (TA)
0
100 in stock
