Seoul Semiconductor
- Seoul Semiconductor manufacturers and packages a wide selection of light emitting diodes (LEDs) for the automotive, lighting, appliance, mobile, signage, and back lighting units (BLU) markets. The company is the world’s fifth largest LED supplier, holding more than 10, 000 patents globally, while offering a wide range of LED technology and production capacity in areas such as "nPola", deep UV LEDs, and "Acrich", the world’s first commercially produced AC LED.
Part Number
Manufacturer
Description
Unit Price
In Stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White, Warm
CCT (K) : 3000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 800 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 120VAC
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 46.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 910 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 100 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 46.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
43 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 800 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 87 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 46.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 650 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 67 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 46.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White, Warm
CCT (K) : 2700K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 650 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 67 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 46.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1360 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 100 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 50.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
27 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White, Neutral
CCT (K) : 4000K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1210 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 87 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 50.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White
CCT (K) : 3000K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1000 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 67 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 50.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White, Warm
CCT (K) : 2700K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1000 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 67 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 50.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White, Cool
CCT (K) : 5000K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 450 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 100 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 33.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White
CCT (K) : 3000K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 330 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 67 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 33.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
Seoul Semiconductor
Manufacturer : Seoul Semiconductor Inc.
Packaging : Tray
Series : Acrich2
Part Status : Obsolete
Type : LED Engine
Color : White, Warm
CCT (K) : 2700K
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 330 lm (Typ)
Current - Test : -
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : 67 lm/W
Current - Max : -
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 33.00mm Diameter
Height : 2.50mm
Light Emitting Surface (LES) : -
Lens Type : Flat
0
100 in stock
