Preci-Dip
- Preci-Dip packs unequaled expertise into cutting-edge interconnect components. Leveraging advanced designs, and top materials, with incomparable Swiss precision,Preci-Dip’s precision tools and contact assembly machines are developed, designed, and produced with passion and expertise. These experts put the principle of vertical single-site command structure put into practice - monitoring each step from raw material to finished product.
Part Number
Manufacturer
Description
Unit Price
In Stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Strip
Series : 714
Part Status : Active
Tail Type : No Tail
Termination : Solder
Length - Overall : 0.136" (3.45mm)
Accepts Pin Diameter : 0.016" ~ 0.021" (0.41mm ~ 0.53mm)
Accepts Square Pin Size : -
Pin Hole Diameter : -
Mounting Hole Diameter : 0.039" ~ 0.051" (0.99mm ~ 1.30mm)
Flange Diameter : 0.055" (1.40mm)
Tail Diameter : -
Socket Depth : 0.124" (3.15mm)
Contact Material : Beryllium Copper
Contact Finish : Gold
Contact Finish Thickness : Flash
0
390 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Mating Target
Number of Contacts : 2
Pitch : 0.100" (2.54mm)
Number of Rows : 1
Row Spacing : -
Mounting Type : Surface Mount
Material : Brass
Contact Finish : Gold
Contact Finish Thickness : 10.0µin (0.25µm)
0
1841 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Mating Target
Number of Contacts : 3
Pitch : 0.100" (2.54mm)
Number of Rows : 1
Row Spacing : -
Mounting Type : Surface Mount
Material : Brass
Contact Finish : Gold
Contact Finish Thickness : 10.0µin (0.25µm)
0
976 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Header
Contact Type : Male Pin
Pitch - Mating : 0.100" (2.54mm)
Number of Positions : 4
Number of Rows : 1
Row Spacing - Mating : -
Number of Positions Loaded : All
Style : Board to Board
Shrouding : Unshrouded
Mounting Type : Through Hole
Termination : Solder
Fastening Type : Push-Pull
Contact Length - Mating : 0.191" (4.85mm)
Contact Length - Post : 0.121" (3.08mm)
Overall Contact Length : 0.438" (11.12mm)
Insulation Height : 0.116" (2.95mm)
Contact Shape : Circular
Contact Finish - Mating : Gold
Contact Finish Thickness - Mating : 10.0µin (0.25µm)
Contact Finish - Post : Gold
Contact Material : Brass
Insulation Material : Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features : -
Operating Temperature : -55°C ~ 125°C
Ingress Protection : -
Material Flammability Rating : UL94 V-0
Insulation Color : Black
Current Rating : 3A
Voltage Rating : 150VDC
0
4635 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Mating Target
Number of Contacts : 4
Pitch : 0.100" (2.54mm)
Number of Rows : 1
Row Spacing : -
Mounting Type : Surface Mount
Material : Brass
Contact Finish : Gold
Contact Finish Thickness : 10.0µin (0.25µm)
0
899 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Mating Target
Number of Contacts : 5
Pitch : 0.100" (2.54mm)
Number of Rows : 1
Row Spacing : -
Mounting Type : Surface Mount
Material : Brass
Contact Finish : Gold
Contact Finish Thickness : 10.0µin (0.25µm)
0
361 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Mating Target
Number of Contacts : 6
Pitch : 0.100" (2.54mm)
Number of Rows : 1
Row Spacing : -
Mounting Type : Surface Mount
Material : Brass
Contact Finish : Gold
Contact Finish Thickness : 10.0µin (0.25µm)
0
1540 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Mating Target
Number of Contacts : 7
Pitch : 0.100" (2.54mm)
Number of Rows : 1
Row Spacing : -
Mounting Type : Surface Mount
Material : Brass
Contact Finish : Gold
Contact Finish Thickness : 10.0µin (0.25µm)
0
475 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Mating Target
Number of Contacts : 8
Pitch : 0.100" (2.54mm)
Number of Rows : 1
Row Spacing : -
Mounting Type : Surface Mount
Material : Brass
Contact Finish : Gold
Contact Finish Thickness : 10.0µin (0.25µm)
0
292 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Mating Target
Number of Contacts : 9
Pitch : 0.100" (2.54mm)
Number of Rows : 1
Row Spacing : -
Mounting Type : Surface Mount
Material : Brass
Contact Finish : Gold
Contact Finish Thickness : 10.0µin (0.25µm)
0
386 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Mating Target
Number of Contacts : 10
Pitch : 0.100" (2.54mm)
Number of Rows : 1
Row Spacing : -
Mounting Type : Surface Mount
Material : Brass
Contact Finish : Gold
Contact Finish Thickness : 10.0µin (0.25µm)
0
638 in stock
Preci-Dip
Manufacturer : Preci-Dip
Packaging : Bulk
Series : 800
Part Status : Active
Connector Type : Header
Contact Type : Male Pin
Pitch - Mating : 0.100" (2.54mm)
Number of Positions : 32
Number of Rows : 1
Row Spacing - Mating : -
Number of Positions Loaded : All
Style : Board to Board
Shrouding : Unshrouded
Mounting Type : Through Hole
Termination : Solder
Fastening Type : Push-Pull
Contact Length - Mating : 0.191" (4.85mm)
Contact Length - Post : 0.121" (3.08mm)
Overall Contact Length : 0.438" (11.12mm)
Insulation Height : 0.116" (2.95mm)
Contact Shape : Circular
Contact Finish - Mating : Gold
Contact Finish Thickness - Mating : 10.0µin (0.25µm)
Contact Finish - Post : Gold
Contact Material : Brass
Insulation Material : Polycyclohexylenedimethylene Terephthalate (PCT), Polyester, Glass Filled
Features : -
Operating Temperature : -55°C ~ 125°C
Ingress Protection : -
Material Flammability Rating : UL94 V-0
Insulation Color : Black
Current Rating : 3A
Voltage Rating : 150VDC
0
267 in stock
