Mechatronics
- Mechatronics is a manufacturer of brushless cooling fans and thermal solutions headquartered near Seattle, WA. Mechatronics product offering includes AC axial fans, DC axial fans, AC blowers, DC blowers, AC motorized impellers and value-added assemblies. In addition to our standard products, we offer tailored solutions to fit customer specific requirements from minor modifications to fully custom products.
With factories located in Indonesia, Taiwan and China, Mechatronics offers technologically advanced products, superior quality, competitive pricing and exceptional service.
Part Number
Manufacturer
Description
Unit Price
In Stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025-H
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 40.0 CFM (1.12m鲁/min)
Static Pressure : 0.170 in H2O (42.3 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 32.0 dB(A)
Power (Watts) : -
RPM : 3200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.182 lb (82.55g)
0
10 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 39.0 CFM (1.09m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 29.0 dB(A)
Power (Watts) : -
RPM : 2400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.174 lb (78.93g)
0
20 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025
Part Status : Active
Voltage - Rated : 24VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 39.0 CFM (1.09m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 29.0 dB(A)
Power (Watts) : -
RPM : 2400 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.174 lb (78.93g)
0
6 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 29.0 CFM (0.812m鲁/min)
Static Pressure : 0.070 in H2O (17.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 22.0 dB(A)
Power (Watts) : -
RPM : 1800 RPM
Termination : 2 Wire Leads
Ingress Protection : IP57 - Dust Protected, Waterproof
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.174 lb (78.93g)
0
33 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025
Part Status : Active
Voltage - Rated : 5VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 34.0 CFM (0.952m鲁/min)
Static Pressure : 0.090 in H2O (22.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 26.0 dB(A)
Power (Watts) : -
RPM : 2100 RPM
Termination : 2 Wire Leads
Ingress Protection : IP57 - Dust Protected, Waterproof
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.174 lb (78.93g)
0
37 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 34.0 CFM (0.952m鲁/min)
Static Pressure : 0.090 in H2O (22.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Thermistor
Noise : 29.0 dB(A)
Power (Watts) : -
RPM : 2100 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.174 lb (78.93g)
0
98 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025-H
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 35.0 CFM (0.980m鲁/min)
Static Pressure : 0.120 in H2O (29.9 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 29.0 dB(A)
Power (Watts) : -
RPM : 2800 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.182 lb (82.55g)
0
9 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 34.0 CFM (0.952m鲁/min)
Static Pressure : 0.090 in H2O (22.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : -
Noise : 29.0 dB(A)
Power (Watts) : -
RPM : 2100 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.174 lb (78.93g)
0
484 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025-H
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 26.0 CFM (0.728m鲁/min)
Static Pressure : 0.070 in H2O (17.4 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Sensor
Noise : 22.0 dB(A)
Power (Watts) : -
RPM : 2000 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.182 lb (82.55g)
0
8 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025-H
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 53.0 CFM (1.48m鲁/min)
Static Pressure : 0.260 in H2O (64.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Speed Sensor (Tach)
Noise : 39.0 dB(A)
Power (Watts) : -
RPM : 4200 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.182 lb (82.55g)
0
783 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 51.0 CFM (1.43m鲁/min)
Static Pressure : 0.180 in H2O (44.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Locked Rotor Sensor
Noise : 35.0 dB(A)
Power (Watts) : -
RPM : 3200 RPM
Termination : 3 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.174 lb (78.93g)
0
12 in stock
Mechatronics
Manufacturer : Mechatronics Fan Group
Series : F8025-H
Part Status : Active
Voltage - Rated : 12VDC
Size / Dimension : Square - 80mm L x 80mm H
Width : 25.00mm
Air Flow : 53.0 CFM (1.48m鲁/min)
Static Pressure : 0.260 in H2O (64.8 Pa)
Bearing Type : Ball
Fan Type : Tubeaxial
Features : Thermistor
Noise : 39.0 dB(A)
Power (Watts) : -
RPM : 4200 RPM
Termination : 2 Wire Leads
Ingress Protection : -
Operating Temperature : -
Approvals : CE, cUL, TUV, UL
Weight : 0.182 lb (82.55g)
0
166 in stock
