Luminus Devices, Inc.
- Luminus Devices, Inc. develops and markets solid-state lighting solutions (SSL) to help its customers migrate from conventional lamp technologies to long-life and energy-efficient LED illumination. Luminus offers a comprehensive range of LED solutions for indoor and outdoor illumination markets as well as high-output specialty lighting solutions for performance-driven markets including consumer displays, entertainment lighting, medical and industrial applications. Luminus is headquartered in Sunnyvale, CA, and has operations in Woburn, Massachusetts and Xiamen, China.
Part Number
Manufacturer
Description
Unit Price
In Stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : CVM-14
Part Status : Not For New Designs
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3150K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 2575 lm (Typ)
Current - Test : 1A
Temperature - Test : 100°C
Voltage - Forward (Vf) (Typ) : 36V
Lumens/Watt @ Current - Test : 72 lm/W
Current - Max : 1A
CRI (Color Rendering Index) : 95
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 19.00mm W
Height : 1.37mm
Light Emitting Surface (LES) : 13.50mm Diameter
Lens Type : Flat
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : Studio
Part Status : Not For New Designs
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5600K 2-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 2800 lm (Typ)
Current - Test : 1A
Temperature - Test : 100°C
Voltage - Forward (Vf) (Typ) : 36V
Lumens/Watt @ Current - Test : 78 lm/W
Current - Max : 1A
CRI (Color Rendering Index) : 95
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 19.00mm W
Height : 1.37mm
Light Emitting Surface (LES) : 13.50mm Diameter
Lens Type : Flat
0
883 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : CVM-14
Part Status : Not For New Designs
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5600K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 2800 lm (Typ)
Current - Test : 1A
Temperature - Test : 100°C
Voltage - Forward (Vf) (Typ) : 36V
Lumens/Watt @ Current - Test : 78 lm/W
Current - Max : 1A
CRI (Color Rendering Index) : 95
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 19.00mm W
Height : 1.37mm
Light Emitting Surface (LES) : 13.50mm Diameter
Lens Type : Flat
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : -
Series : Studio
Part Status : Not For New Designs
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K 2-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 1.8A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 36V
Lumens/Watt @ Current - Test : -
Current - Max : 1.8A
CRI (Color Rendering Index) : 95
Viewing Angle : 120°
Features : -
Size / Dimension : 21.50mm L x 21.50mm W
Height : 1.37mm
Light Emitting Surface (LES) : 17.50mm Diameter
Lens Type : Flat
0
101 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : CVM-18
Part Status : Not For New Designs
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3050K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 4425 lm (Typ)
Current - Test : 1.8A
Temperature - Test : 100°C
Voltage - Forward (Vf) (Typ) : 36V
Lumens/Watt @ Current - Test : 68 lm/W
Current - Max : 1.8A
CRI (Color Rendering Index) : 95
Viewing Angle : 120°
Features : -
Size / Dimension : 21.50mm L x 21.50mm W
Height : 1.37mm
Light Emitting Surface (LES) : 17.50mm Diameter
Lens Type : Flat
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : -
Series : Studio
Part Status : Not For New Designs
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5600K 2-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 1.8A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 36V
Lumens/Watt @ Current - Test : -
Current - Max : 1.8A
CRI (Color Rendering Index) : 95
Viewing Angle : 120°
Features : -
Size / Dimension : 21.50mm L x 21.50mm W
Height : 1.37mm
Light Emitting Surface (LES) : 17.50mm Diameter
Lens Type : Flat
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : CVM-18
Part Status : Not For New Designs
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5600K
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 4650 lm (Typ)
Current - Test : 1.8A
Temperature - Test : 100°C
Voltage - Forward (Vf) (Typ) : 36V
Lumens/Watt @ Current - Test : 72 lm/W
Current - Max : 1.8A
CRI (Color Rendering Index) : 95
Viewing Angle : 120°
Features : -
Size / Dimension : 21.50mm L x 21.50mm W
Height : 1.37mm
Light Emitting Surface (LES) : 17.50mm Diameter
Lens Type : Flat
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : -
Series : Studio
Part Status : Active
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 3000K 2-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 4.2A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 36V
Lumens/Watt @ Current - Test : -
Current - Max : 4.2A
CRI (Color Rendering Index) : 95
Viewing Angle : 120°
Features : -
Size / Dimension : 31.50mm L x 31.50mm W
Height : 1.37mm
Light Emitting Surface (LES) : 26.50mm Diameter
Lens Type : Flat
0
66 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : -
Series : Studio
Part Status : Active
Type : Chip On Board (COB)
Color : White, Cool
CCT (K) : 5600K 2-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : -
Current - Test : 4.2A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : 36V
Lumens/Watt @ Current - Test : -
Current - Max : 4.2A
CRI (Color Rendering Index) : 95
Viewing Angle : 120°
Features : -
Size / Dimension : 31.50mm L x 31.50mm W
Height : 1.37mm
Light Emitting Surface (LES) : 26.50mm Diameter
Lens Type : Flat
0
8 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : *
Part Status : Not For New Designs
Type : -
Color : -
CCT (K) : -
Wavelength : -
Configuration : -
Flux @ Current/Temperature - Test : -
Current - Test : -
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : -
Viewing Angle : -
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : -
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : CXM-11
Part Status : Not For New Designs
Type : Chip On Board (COB)
Color : White, Warm
CCT (K) : 2700K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Square
Flux @ Current/Temperature - Test : 1806 lm (Typ)
Current - Test : 480mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 35V
Lumens/Watt @ Current - Test : 108 lm/W
Current - Max : 960mA
CRI (Color Rendering Index) : 80
Viewing Angle : 120°
Features : -
Size / Dimension : 19.00mm L x 19.00mm W
Height : 1.37mm
Light Emitting Surface (LES) : 11.00mm Diameter
Lens Type : Flat
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : *
Part Status : Not For New Designs
Type : -
Color : -
CCT (K) : -
Wavelength : -
Configuration : -
Flux @ Current/Temperature - Test : -
Current - Test : -
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : -
Viewing Angle : -
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : -
0
100 in stock
