Luminus Devices, Inc.
- Luminus Devices, Inc. develops and markets solid-state lighting solutions (SSL) to help its customers migrate from conventional lamp technologies to long-life and energy-efficient LED illumination. Luminus offers a comprehensive range of LED solutions for indoor and outdoor illumination markets as well as high-output specialty lighting solutions for performance-driven markets including consumer displays, entertainment lighting, medical and industrial applications. Luminus is headquartered in Sunnyvale, CA, and has operations in Woburn, Massachusetts and Xiamen, China.
Part Number
Manufacturer
Description
Unit Price
In Stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : Green
CCT (K) : -
Wavelength : 537nm
Configuration : Square
Flux @ Current/Temperature - Test : 855 lm (Typ)
Current - Test : 3.15A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.4V
Lumens/Watt @ Current - Test : 80 lm/W
Current - Max : 27A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : Green
CCT (K) : -
Wavelength : 537nm
Configuration : Square
Flux @ Current/Temperature - Test : 855 lm (Typ)
Current - Test : 3.15A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.4V
Lumens/Watt @ Current - Test : 80 lm/W
Current - Max : 27A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : Green
CCT (K) : -
Wavelength : 537nm
Configuration : Square
Flux @ Current/Temperature - Test : 855 lm (Typ)
Current - Test : 3.15A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.4V
Lumens/Watt @ Current - Test : 80 lm/W
Current - Max : 27A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : Green
CCT (K) : -
Wavelength : 537nm
Configuration : Square
Flux @ Current/Temperature - Test : 855 lm (Typ)
Current - Test : 3.15A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.4V
Lumens/Watt @ Current - Test : 80 lm/W
Current - Max : 27A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : Green
CCT (K) : -
Wavelength : 537nm
Configuration : Square
Flux @ Current/Temperature - Test : 855 lm (Typ)
Current - Test : 3.15A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.4V
Lumens/Watt @ Current - Test : 80 lm/W
Current - Max : 27A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Discontinued at
Type : Chip On Board (COB)
Color : Red
CCT (K) : -
Wavelength : 624nm
Configuration : Square
Flux @ Current/Temperature - Test : 400 lm (Typ)
Current - Test : 3.2A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 2V
Lumens/Watt @ Current - Test : 63 lm/W
Current - Max : 27A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Active
Color : Red
Wavelength : 623nm (611nm ~ 635nm)
Current - Test : 3.2A
Voltage - Forward (Vf) (Typ) : 2V
Lumens/Watt @ Current - Test : 63 lm/W
Current - Max : 27A
Flux @ Current/Temperature - Test : 400 lm (Typ)
Temperature - Test : 25°C
Viewing Angle : 100°
Mounting Type : Surface Mount
Package / Case : 0404 (1010 Metric)
Supplier Device Package : SMD
Size / Dimension : 0.433" L x 0.394" W (11.00mm x 10.00mm)
Height - Seated (Max) : 0.215" (5.45mm)
0
66 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : Red
CCT (K) : -
Wavelength : 624nm
Configuration : Square
Flux @ Current/Temperature - Test : 400 lm (Typ)
Current - Test : 3.2A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 2V
Lumens/Watt @ Current - Test : 63 lm/W
Current - Max : 27A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : Chip On Board (COB)
Color : Red
CCT (K) : -
Wavelength : 624nm
Configuration : Square
Flux @ Current/Temperature - Test : 400 lm (Typ)
Current - Test : 3.2A
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 2V
Lumens/Watt @ Current - Test : 63 lm/W
Current - Max : 27A
CRI (Color Rendering Index) : 70
Viewing Angle : 100°
Features : -
Size / Dimension : 11.00mm L x 10.00mm W
Height : 5.40mm
Light Emitting Surface (LES) : 8.00mm Diameter
Lens Type : Domed
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : LED Module
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : -
Current - Test : 3.15A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : 83 (Typ)
Viewing Angle : -
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : -
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : Tray
Series : SST-90
Part Status : Obsolete
Type : LED Module
Color : White, Warm
CCT (K) : 3000K
Wavelength : -
Configuration : Rectangle
Flux @ Current/Temperature - Test : -
Current - Test : 3.15A
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : 83 (Typ)
Viewing Angle : -
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : -
0
100 in stock
Luminus Devices
Manufacturer : Luminus Devices Inc.
Packaging : -
Series : SST-90
Part Status : Obsolete
Color : White, Warm
CCT (K) : 3000K
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : -
Current - Test : 3.15A
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : 83 (Typ)
Current - Max : -
Viewing Angle : -
Mounting Type : -
Package / Case : -
Supplier Device Package : -
Size / Dimension : 0.433" L x 0.394" W (11.00mm x 10.00mm)
Height - Seated (Max) : 0.067" (1.71mm)
0
1775 in stock
