Lumileds
- Companies developing automotive, mobile, IoT and illumination lighting applications need a partner who can collaborate with them to push the boundaries of light. With over 100 years of inventions and industry firsts, Lumileds is a global lighting solutions company that helps customers around the world deliver differentiated solutions to gain and maintain a competitive edge. As the inventor of Xenon technology, a pioneer in halogen lighting and the leader in high performance LEDs, Lumileds builds innovation, quality and reliability into its technology, products and every customer engagement. Together with its customers, Lumileds is making the world safer, better and more beautiful—with light.
Part Number
Manufacturer
Description
Unit Price
In Stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON K
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 1875 lm (Typ)
Current - Test : 350mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 42V
Lumens/Watt @ Current - Test : 128 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 80
Viewing Angle : 100°
Features : -
Size / Dimension : 24.20mm Diameter
Height : 3.42mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON K
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 1860 lm (1680 lm ~ 2010 lm)
Current - Test : 350mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 42V
Lumens/Watt @ Current - Test : 127 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 80
Viewing Angle : 100°
Features : -
Size / Dimension : 24.35mm L x 24.45mm W
Height : 3.42mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
216 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON K
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 2860 lm (Typ)
Current - Test : 350mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 63V
Lumens/Watt @ Current - Test : 130 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 80
Viewing Angle : 100°
Features : -
Size / Dimension : 30.00mm Diameter
Height : 3.42mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON K
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 2660 lm (2530 lm ~ 3030 lm)
Current - Test : 350mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 63V
Lumens/Watt @ Current - Test : 121 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 80
Viewing Angle : 100°
Features : -
Size / Dimension : 30.00mm L x 30.00mm W
Height : 3.42mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
181 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON K
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 660 lm (625 lm ~ 750 lm)
Current - Test : 175mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 31.5V
Lumens/Watt @ Current - Test : 120 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 80
Viewing Angle : 100°
Features : -
Size / Dimension : 21.65mm L x 21.75mm W
Height : 3.42mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON K
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 330 lm (310 lm ~ 370 lm)
Current - Test : 87.5mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 31.5V
Lumens/Watt @ Current - Test : 120 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 80
Viewing Angle : 100°
Features : -
Size / Dimension : 17.67mm L x 17.67mm W
Height : 3.42mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON K
Part Status : Obsolete
Type : LED Module
Color : White, Neutral
CCT (K) : 4000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 430 lm (410 lm ~ 490 lm)
Current - Test : 87.5mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 42V
Lumens/Watt @ Current - Test : 117 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 80
Viewing Angle : 100°
Features : -
Size / Dimension : 17.67mm L x 17.67mm W
Height : 3.42mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : -
Series : *
Part Status : Obsolete
Type : -
Color : -
CCT (K) : -
Wavelength : -
Configuration : -
Flux @ Current/Temperature - Test : -
Current - Test : -
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : -
Viewing Angle : -
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : -
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : -
Series : *
Part Status : Obsolete
Type : -
Color : -
CCT (K) : -
Wavelength : -
Configuration : -
Flux @ Current/Temperature - Test : -
Current - Test : -
Temperature - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
Current - Max : -
CRI (Color Rendering Index) : -
Viewing Angle : -
Features : -
Size / Dimension : -
Height : -
Light Emitting Surface (LES) : -
Lens Type : -
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON K
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 463 lm (440 lm ~ 530 lm)
Current - Test : 350mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 10.5V
Lumens/Watt @ Current - Test : 126 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 80
Viewing Angle : 100°
Features : -
Size / Dimension : 17.67mm L x 17.67mm W
Height : 3.42mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON K
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 933 lm (890 lm ~ 1070 lm)
Current - Test : 350mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 21V
Lumens/Watt @ Current - Test : 127 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 80
Viewing Angle : 100°
Features : -
Size / Dimension : 21.75mm L x 21.75mm W
Height : 3.42mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lumileds
Manufacturer : Lumileds
Packaging : Tray
Series : LUXEON K
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : 5000K 3-Step MacAdam Ellipse
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 1850 lm (1760 lm ~ 2110 lm)
Current - Test : 350mA
Temperature - Test : 85°C
Voltage - Forward (Vf) (Typ) : 42V
Lumens/Watt @ Current - Test : 126 lm/W
Current - Max : 1.05A
CRI (Color Rendering Index) : 80
Viewing Angle : 100°
Features : -
Size / Dimension : 24.35mm L x 24.45mm W
Height : 3.42mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
