Lite-On, Inc.
- Lite-On started producing LED lamps in 1975 and has steadily grown into one of the world's largest optoelectronics manufacturers by providing customers with both visible and infrared product solutions. High volume capacities for commodity items and application specific products, combined with strong R&D and vertical integration, have proven to be key distinguishing factors in Lite-On's success.
Part Number
Manufacturer
Description
Unit Price
In Stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : Bulk
Series : LOPL
Part Status : Obsolete
Type : LED Module
Color : Amber
CCT (K) : -
Wavelength : 590nm
Configuration : Round
Flux @ Current/Temperature - Test : 28 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 2.57V
Lumens/Watt @ Current - Test : 31 lm/W
Current - Max : 350mA
CRI (Color Rendering Index) : -
Viewing Angle : 110°
Features : -
Size / Dimension : 8.00mm Diameter
Height : 3.15mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : Bulk
Series : LOPL
Part Status : Obsolete
Type : LED Module
Color : Blue
CCT (K) : -
Wavelength : 470nm
Configuration : Round
Flux @ Current/Temperature - Test : 12 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.8V
Lumens/Watt @ Current - Test : 9 lm/W
Current - Max : 350mA
CRI (Color Rendering Index) : -
Viewing Angle : 110°
Features : -
Size / Dimension : 8.00mm Diameter
Height : 3.15mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : Bulk
Series : LOPL
Part Status : Obsolete
Type : LED Module
Color : Cyan
CCT (K) : -
Wavelength : 505nm
Configuration : Round
Flux @ Current/Temperature - Test : 32 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.8V
Lumens/Watt @ Current - Test : 24 lm/W
Current - Max : 350mA
CRI (Color Rendering Index) : -
Viewing Angle : 110°
Features : -
Size / Dimension : 8.00mm Diameter
Height : 3.15mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : Bulk
Series : LOPL
Part Status : Obsolete
Type : LED Module
Color : Green
CCT (K) : -
Wavelength : 530nm
Configuration : Round
Flux @ Current/Temperature - Test : 40 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.8V
Lumens/Watt @ Current - Test : 30 lm/W
Current - Max : 350mA
CRI (Color Rendering Index) : -
Viewing Angle : 110°
Features : -
Size / Dimension : 8.00mm Diameter
Height : 3.15mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : Tray
Series : LOPL
Part Status : Obsolete
Type : LED Module
Color : Red
CCT (K) : -
Wavelength : 617nm
Configuration : Starboard
Flux @ Current/Temperature - Test : 44 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 2.57V
Lumens/Watt @ Current - Test : 49 lm/W
Current - Max : 350mA
CRI (Color Rendering Index) : -
Viewing Angle : 110°
Features : -
Size / Dimension : 19.91mm Diameter
Height : -
Light Emitting Surface (LES) : 8.00mm
Lens Type : Domed
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : Bulk
Series : LOPL
Part Status : Obsolete
Type : LED Module
Color : White, Warm
CCT (K) : -
Wavelength : -
Configuration : Round
Flux @ Current/Temperature - Test : 35 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.8V
Lumens/Watt @ Current - Test : 26 lm/W
Current - Max : 350mA
CRI (Color Rendering Index) : 80 (Typ)
Viewing Angle : 110°
Features : -
Size / Dimension : 8.00mm Diameter
Height : 3.15mm
Light Emitting Surface (LES) : -
Lens Type : Domed
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : Tray
Series : LOPL
Part Status : Obsolete
Type : LED Module
Color : Red
CCT (K) : -
Wavelength : 625nm
Configuration : Starboard
Flux @ Current/Temperature - Test : 37 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 2.57V
Lumens/Watt @ Current - Test : 41 lm/W
Current - Max : 350mA
CRI (Color Rendering Index) : -
Viewing Angle : 110°
Features : -
Size / Dimension : 19.91mm Diameter
Height : -
Light Emitting Surface (LES) : 8.00mm
Lens Type : Domed
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : Tray
Series : LOPL
Part Status : Obsolete
Type : LED Module
Color : White, Cool
CCT (K) : -
Wavelength : -
Configuration : Starboard
Flux @ Current/Temperature - Test : 45 lm (Typ)
Current - Test : 350mA
Temperature - Test : 25°C
Voltage - Forward (Vf) (Typ) : 3.8V
Lumens/Watt @ Current - Test : 34 lm/W
Current - Max : 350mA
CRI (Color Rendering Index) : 85 (Typ)
Viewing Angle : 110°
Features : -
Size / Dimension : 19.91mm Diameter
Height : -
Light Emitting Surface (LES) : 8.00mm
Lens Type : Domed
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : -
Series : -
Part Status : Obsolete
Color : -
CCT (K) : -
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : -
Current - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : -
Current - Max : -
Viewing Angle : -
Mounting Type : -
Package / Case : -
Supplier Device Package : -
Size / Dimension : -
Height - Seated (Max) : -
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : -
Series : -
Part Status : Obsolete
Color : -
CCT (K) : -
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : -
Current - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : -
Current - Max : -
Viewing Angle : -
Mounting Type : -
Package / Case : -
Supplier Device Package : -
Size / Dimension : -
Height - Seated (Max) : -
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : -
Series : -
Part Status : Obsolete
Color : -
CCT (K) : -
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : -
Current - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : -
Current - Max : -
Viewing Angle : -
Mounting Type : -
Package / Case : -
Supplier Device Package : -
Size / Dimension : -
Height - Seated (Max) : -
0
100 in stock
Lite-On, Inc.
Manufacturer : Lite-On Inc.
Packaging : -
Series : -
Part Status : Obsolete
Color : -
CCT (K) : -
Flux @ 85°C, Current - Test : -
Flux @ 25°C, Current - Test : -
Current - Test : -
Voltage - Forward (Vf) (Typ) : -
Lumens/Watt @ Current - Test : -
CRI (Color Rendering Index) : -
Current - Max : -
Viewing Angle : -
Mounting Type : -
Package / Case : -
Supplier Device Package : -
Size / Dimension : -
Height - Seated (Max) : -
0
100 in stock
