- Johanson Technology was formed to specifically focus on RF, microwave and optical markets. With a highly experienced design team, we produce superior high frequency ceramic solutions through optimization of ceramics, inks and RF circuit designs. Our focus on high frequency has enabled JTI to provide products with exceptional high frequency performance. We have received certification to the ISO9001-2000 standard.
Johanson Technology provides high frequency ceramic solutions for Cellular, WLAN, Bluetooth, WiMax, WiFi, UWB, RF/Microwave, Millimeter Wave, and Fiber Optic applications, as well as custom high frequency ceramic solutions. We offer a broad range of standard products including: Multilayer Capacitors, Single Layer Capacitors, RF Inductors, RF Wire-wound Inductors, Chip Antennas, Baluns, Balanced Filters, Band Pass Filters, High Pass Filter, Low Pass Filters, Couplers, and Diplexers.
Part Number
Manufacturer
Description
Unit Price
In Stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Series : 5250
Part Status : Obsolete
Frequency Range : 5.15GHz ~ 5.35GHz
Impedance - Unbalanced/Balanced : 50 / 100 Ohm
Phase Difference : 180° ±15°
Insertion Loss (Max) : 1.0dB
Return Loss (Min) : 9.5dB
Package / Case : 0603 (1608 Metric)
Mounting Type : Surface Mount
0
100 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Tape & Reel (TR)
Series : 5250
Part Status : Obsolete
Frequency Range : 5.15GHz ~ 5.35GHz
Impedance - Unbalanced/Balanced : 50 / 100 Ohm
Phase Difference : 180° ±10°
Insertion Loss (Max) : 1.2dB
Return Loss (Min) : 9.5dB
Package / Case : 0805 (2012 Metric)
Mounting Type : Surface Mount
0
100 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Coupler Type : Coupler, With Filter
Frequency : 4.9GHz ~ 5.85GHz
Coupling Factor : 15 ± 1dB
Applications : -
Insertion Loss : 0.8dB
Power - Max : 2W
Isolation : 22dB
Return Loss : -20dB
Package / Case : 0805 (2012 Metric), 8 PC Pad
Supplier Device Package : 0805 (2012 Metric)
0
3732 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 5325
Part Status : Obsolete
Frequency Range : 5.15GHz ~ 5.5GHz
Impedance - Unbalanced/Balanced : 50 / 50 Ohm
Phase Difference : 180° ±10°
Insertion Loss (Max) : 1.0dB
Return Loss (Min) : 9.5dB
Package / Case : 0805 (2012 Metric)
Mounting Type : Surface Mount
0
1580 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Frequency : -
Bandwidth : -
Filter Type : -
Ripple : -
Insertion Loss : -
Mounting Type : -
Package / Case : -
Size / Dimension : -
Height (Max) : -
0
100 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Frequency : -
Bandwidth : -
Filter Type : -
Ripple : -
Insertion Loss : -
Mounting Type : -
Package / Case : -
Size / Dimension : -
Height (Max) : -
0
100 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Frequency : 5.3875GHz Center
Bandwidth : 975MHz
Filter Type : Band Pass
Ripple : -
Insertion Loss : 1.8dB
Mounting Type : Surface Mount
Package / Case : 0805 (2012 Metric), 6 PC Pad
Size / Dimension : 0.079" L x 0.049" W (2.00mm x 1.25mm)
Height (Max) : 0.041" (1.05mm)
0
100 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Frequency Group : SHF (f > 4 GHz)
Frequency (Center/Band) : 5.4GHz
Frequency Range : 4.9GHz ~ 5.9GHz
Antenna Type : Chip
Number of Bands : 1
VSWR : -
Return Loss : -8.5dB
Gain : 2dBi
Power - Max : 500mW
Features : -
Termination : Solder
Ingress Protection : -
Mounting Type : Surface Mount
Height (Max) : 0.051" (1.30mm)
Applications : -
0
3520 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Tape & Reel (TR)
Series : -
Part Status : Obsolete
Frequency Range : 4.9GHz ~ 5.95GHz
Impedance - Unbalanced/Balanced : 50 / 200 Ohm
Phase Difference : 180° ±10°
Insertion Loss (Max) : 1.2dB
Return Loss (Min) : 9.5dB
Package / Case : 0603 (1608 Metric), 6 PC Pad
Mounting Type : Surface Mount
0
100 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 5400
Part Status : Active
Frequency Range : 4.9GHz ~ 5.87GHz
Impedance - Unbalanced/Balanced : 50 / 100 Ohm
Phase Difference : 180° ±10°
Insertion Loss (Max) : 1.0dB
Return Loss (Min) : 9.5dB
Package / Case : 0603 (1608 Metric)
Mounting Type : Surface Mount
0
2967 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 5400
Part Status : Active
Frequency Range : 4.9GHz ~ 5.9GHz
Impedance - Unbalanced/Balanced : 50 / 50 Ohm
Phase Difference : 180° ±10°
Insertion Loss (Max) : 1.0dB
Return Loss (Min) : 9.5dB
Package / Case : 0805 (2012 Metric)
Mounting Type : Surface Mount
0
2467 in stock
Johanson Technology
Manufacturer : Johanson Technology Inc.
Packaging : Cut Tape (CT)
Alternate Packaging
Series : 5400
Part Status : Active
Frequency Range : 4.9GHz ~ 5.9GHz
Impedance - Unbalanced/Balanced : 50 / 100 Ohm
Phase Difference : 180° ±10°
Insertion Loss (Max) : 1.0dB
Return Loss (Min) : 9.5dB
Package / Case : 0805 (2012 Metric)
Mounting Type : Surface Mount
0
12799 in stock
