Central Semiconductor
- Since 1974, Central Semiconductor has manufactured innovative discrete semiconductors used in electronic products worldwide. Devices currently include standard and custom small signal transistors, bipolar power transistors, MOSFETs, diodes, rectifiers, protection devices, current limiting diodes, bridge rectifiers, thyristors, and silicon carbide devices. Central’s devices are available in industry standard surface mount and through-hole packages, bare die, TLMs (Tiny Leadless Modules™), and MDMs (Multi Discrete Modules™). Central has earned a reputation as a manufacturer of the highest quality products consistently delivered on-time, and a provider of exceptional value-added services.
Part Number
Manufacturer
Description
Unit Price
In Stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Voltage - Zener (Nom) (Vz) : 68V
Tolerance : ±5%
Power - Max : 350mW
Impedance (Max) (Zzt) : 230 Ohms
Current - Reverse Leakage @ Vr : 100nA @ 52V
Voltage - Forward (Vf) (Max) @ If : 900mV @ 10mA
Operating Temperature : -65°C ~ 150°C
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
0
5988 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Voltage - Zener (Nom) (Vz) : 75V
Tolerance : ±5%
Power - Max : 350mW
Impedance (Max) (Zzt) : 270 Ohms
Current - Reverse Leakage @ Vr : 100nA @ 56V
Voltage - Forward (Vf) (Max) @ If : 900mV @ 10mA
Operating Temperature : -65°C ~ 150°C
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
0
5876 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Configuration : 1 Pair Common Anode
Voltage - Zener (Nom) (Vz) : 12.05V
Tolerance : ±5%
Power - Max : 350mW
Impedance (Max) (Zzt) : 250 Ohms
Current - Reverse Leakage @ Vr : 100nA @ 8V
Voltage - Forward (Vf) (Max) @ If : 900mV @ 10mA
Operating Temperature : -65°C ~ 150°C
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
0
2924 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Configuration : 1 Pair Common Anode
Voltage - Zener (Nom) (Vz) : 14.7V
Tolerance : -
Power - Max : 350mW
Impedance (Max) (Zzt) : 30 Ohms
Current - Reverse Leakage @ Vr : 50nA @ 10.5V
Voltage - Forward (Vf) (Max) @ If : 900mV @ 10mA
Operating Temperature : -65°C ~ 175°C
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
0
2330 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Configuration : 1 Pair Common Anode
Voltage - Zener (Nom) (Vz) : 24.2V
Tolerance : -
Power - Max : 350mW
Impedance (Max) (Zzt) : 70 Ohms
Current - Reverse Leakage @ Vr : 50nA @ 16.8V
Voltage - Forward (Vf) (Max) @ If : 900mV @ 10mA
Operating Temperature : -65°C ~ 175°C
Mounting Type : Surface Mount
Package / Case : TO-236-3, SC-59, SOT-23-3
Supplier Device Package : SOT-23
0
3387 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 200V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 1.1V @ 1A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 5µA @ 200V
Capacitance @ Vr, F : 8pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB
Operating Temperature - Junction : -65°C ~ 150°C
0
25048 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 200V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 1.1V @ 1A
Speed : Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 5µA @ 200V
Capacitance @ Vr, F : 8pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AC, SMA
Supplier Device Package : SMA
Operating Temperature - Junction : -65°C ~ 150°C
0
17427 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 400V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 1.1V @ 1A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 10µA @ 400V
Capacitance @ Vr, F : 8pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB
Operating Temperature - Junction : -65°C ~ 175°C
0
14564 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 400V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 1.1V @ 1A
Speed : Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 5µA @ 400V
Capacitance @ Vr, F : 8pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AC, SMA
Supplier Device Package : SMA
Operating Temperature - Junction : -65°C ~ 150°C
0
21303 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 600V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 1.1V @ 1A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 10µA @ 600V
Capacitance @ Vr, F : 8pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB
Operating Temperature - Junction : -65°C ~ 175°C
0
5640 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 600V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 1.1V @ 1A
Speed : Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 5µA @ 600V
Capacitance @ Vr, F : 8pF @ 4V, 1MHz
Mounting Type : Surface Mount
Package / Case : DO-214AC, SMA
Supplier Device Package : SMA
Operating Temperature - Junction : -65°C ~ 150°C
0
44001 in stock
Central Semiconductor
Manufacturer : Central Semiconductor Corp
Packaging : Cut Tape (CT)
Alternate Packaging
Series : -
Part Status : Active
Diode Type : Standard
Voltage - DC Reverse (Vr) (Max) : 1000V
Current - Average Rectified (Io) : 1A
Voltage - Forward (Vf) (Max) @ If : 1.1V @ 1A
Speed : Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) : -
Current - Reverse Leakage @ Vr : 10µA @ 1000V
Capacitance @ Vr, F : -
Mounting Type : Surface Mount
Package / Case : DO-214AA, SMB
Supplier Device Package : SMB
Operating Temperature - Junction : -60°C ~ 175°C
0
5798 in stock
