API Technologies Corp.
- API Technologies Corp. is a leading technology provider of RF/microwave, microelectronics, and security technologies for critical and high-reliability applications. The company's international customers include leading Fortune 500 firms, as well as the governments of the U.S., Canada, the United Kingdom, NATO and the European Union. Featured product brands include: Spectrum Microwave, National Hybrid, Spectrum Control, Spectrum Power, Spectrum Sensors, Cryptek, ION Networks, SST, Filtran, and EMCON.
Part Number
Manufacturer
Description
Unit Price
In Stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 2nd
Technology : LC
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 70dB @ 100MHz ~ 1GHz
Resistance - Channel (Ohms) : 0.008
Current : 15A
Values : C = 1.4µF
ESD Protection : No
Operating Temperature : -55°C ~ 125°C
Applications : General Purpose
Voltage - Rated : 50V
Mounting Type : Chassis Mount
Package / Case : Axial, Bushing - 2 Solder Eyelets
Size / Dimension : 0.410" Dia x 0.572" L (10.42mm x 14.54mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 80dB @ 100MHz ~ 1GHz
Resistance - Channel (Ohms) : 0.77
Current : 300mA
Values : C = 2.8µF
ESD Protection : No
Operating Temperature : -
Applications : General Purpose
Voltage - Rated : 50V
Mounting Type : Chassis Mount
Package / Case : Axial, Bushing - 2 Solder Eyelets
Size / Dimension : 0.375" Dia x 0.892" L (9.52mm x 22.65mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 80dB @ 100MHz ~ 1GHz
Resistance - Channel (Ohms) : 0.07
Current : 2A
Values : C = 1.5µF
ESD Protection : No
Operating Temperature : -
Applications : General Purpose
Voltage - Rated : 50V
Mounting Type : Chassis Mount
Package / Case : Axial, Bushing - 2 Solder Eyelets
Size / Dimension : 0.416" Dia x 0.892" L (10.57mm x 22.65mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 80dB @ 100MHz ~ 1GHz
Resistance - Channel (Ohms) : 0.07
Current : 2A
Values : C = 1.5µF
ESD Protection : No
Operating Temperature : -
Applications : General Purpose
Voltage - Rated : 50V
Mounting Type : -
Package / Case : Axial, Bushing - 2 Solder Eyelets
Size / Dimension : 0.416" Dia x 0.770" L (10.57mm x 19.56mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 2nd
Technology : LC
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 70dB @ 100MHz ~ 1GHz
Resistance - Channel (Ohms) : 0.01
Current : 10A
Values : C = 1.4µF
ESD Protection : No
Operating Temperature : -
Applications : General Purpose
Voltage - Rated : 50V
Mounting Type : Chassis Mount
Package / Case : Axial, Bushing - 2 Solder Eyelets
Size / Dimension : 0.375" Dia x 0.902" L (9.52mm x 22.92mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 2nd
Technology : LC
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 70dB @ 100MHz ~ 1GHz
Resistance - Channel (Ohms) : 0.008
Current : 15A
Values : C = 1.4µF
ESD Protection : No
Operating Temperature : -55°C ~ 125°C
Applications : General Purpose
Voltage - Rated : 50V
Mounting Type : Chassis Mount
Package / Case : Axial, Bushing - 2 Solder Eyelets
Size / Dimension : 0.375" Dia x 0.490" L (9.52mm x 12.44mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 50dB @ 100MHz ~ 300MHz
Resistance - Channel (Ohms) : 0.01
Current : 10A
Values : C = 1750pF
ESD Protection : No
Operating Temperature : -55°C ~ 125°C
Applications : General Purpose
Voltage - Rated : 200V
Mounting Type : Chassis Mount
Package / Case : Axial, Bushing, 1 Turret Lead
Size / Dimension : 0.136" Dia x 0.250" L (3.45mm x 6.35mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 65dB @ 100MHz
Resistance - Channel (Ohms) : 0.01
Current : 10A
Values : C = 5500pF
ESD Protection : No
Operating Temperature : -55°C ~ 125°C
Applications : General Purpose
Voltage - Rated : 300V
Mounting Type : Chassis Mount
Package / Case : Axial, Bushing - 1 Turret Lead, 1 Hooked Lead
Size / Dimension : 0.250" Dia x 0.687" L (6.35mm x 17.45mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Bulk
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 45dB @ 100MHz
Resistance - Channel (Ohms) : 0.01
Current : 10A
Values : C = 3000pF
ESD Protection : No
Operating Temperature : -55°C ~ 125°C
Applications : General Purpose
Voltage - Rated : 200V
Mounting Type : Chassis Mount
Package / Case : Axial, Bushing, 1 Turret Lead
Size / Dimension : 0.187" Dia x 0.359" L (4.75mm x 9.12mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 2nd
Technology : LC
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 43dB @ 100MHz
Resistance - Channel (Ohms) : 0.01
Current : 10A
Values : C = 0.022µF
ESD Protection : No
Operating Temperature : -
Applications : General Purpose
Voltage - Rated : 100V
Mounting Type : -
Package / Case : Axial, Bushing
Size / Dimension : 0.187" Dia x 0.360" L (4.75mm x 9.14mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 45dB @ 100MHz
Resistance - Channel (Ohms) : 0.01
Current : 10A
Values : C = 3000pF
ESD Protection : No
Operating Temperature : -55°C ~ 125°C
Applications : General Purpose
Voltage - Rated : 100V
Mounting Type : Chassis Mount
Package / Case : Axial, Bushing
Size / Dimension : 0.187" Dia x 0.360" L (4.75mm x 9.14mm)
Height : -
0
100 in stock
API Technologies Corp.
Manufacturer : API Technologies Corp
Packaging : Tray
Series : -
Part Status : Discontinued at
Type : Low Pass
Filter Order : 3rd
Technology : LC (Pi)
Number of Channels : 1
Center / Cutoff Frequency : -
Attenuation Value : 65dB @ 100MHz
Resistance - Channel (Ohms) : 0.01
Current : 10A
Values : C = 5500pF
ESD Protection : No
Operating Temperature : -55°C ~ 125°C
Applications : General Purpose
Voltage - Rated : 100V
Mounting Type : Chassis Mount
Package / Case : Axial, Bushing, 1 Turret Lead
Size / Dimension : 0.187" Dia x 0.359" L (4.75mm x 9.13mm)
Height : -
0
100 in stock
